Tractor · 1972Unverified
County 1254
County 1254 — Four-wheel Drive (4WD) tractor · 125 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
125 hp
Weight
5615 kg
Hover a source tag to verify
Overview
ManufacturerCountyReference
Four-wheel Drive (4WD) tractorReference
Built in Fleet, EnglandReference
Drive4x4 4WDReference
Power steeringReference
Wet disc brakesReference
Cab standard with available air-conditioning.Reference
Engine
Ford 6.6L 6-cyl dieselReference
Fuel tank162.8 LReference
Engine (gross)93.2 kWReference
FordReference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.6 LReference
Bore/Stroke112 x 112 mmReference
Power (gross)93.2 kWReference
Rated RPM2300Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speed two-speed power shiftReference
TransmissionDual PowerReference
Typetwo-speed power shiftReference
Gears16 forward and 4 reverseReference
PTO & Hydraulics
Typeopen centerReference
Pump flow45.4 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear PTOindependentReference
Rear PTO Type1000 (1.375)Reference
Engine RPM1000@1935Reference
Dimensions
Wheelbase205 cmReference
Weight5615 kgReference
Front tire16.9/14-34Reference
Rear tire16.9/14-34Reference
Ag front16.9/14-34Reference
Ag rear16.9/14-34Reference
Ag front18.4/15-34Reference
Ag front23.1/18-30Reference
Ag front23.1/18-34Reference
Ag rear18.4/15-34Reference
Ag rear23.1/18-30Reference
Ag rear23.1/18-34Reference
Length403 cmReference
Width229 cmReference
Height (cab)295 cmReference
Ground clearance33 cmReference
Front tread172 to 223 cmReference
Rear tread172 to 223 cmReference
Electrical
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
