Tractor · 1974Unverified

County 764

Name: County 764
Brand: County

County 764 — Row-Crop tractor · 73 hp. Reference specifications; pending source verification.

The County 764 is a tractor with a rated power of 73 hp, a mid-range figure for its class. Construction of the County 764 took place from 1974 to 1976. It features a 4-cylinder diesel liquid-cooled engine, coupled with four-wheel drive and an 8-speed gearbox. The tractor's listed operating weight is 4100 kg, suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

73 hp

Weight

4100 kg

Catalogue coverage

Variants represented

Richest spec table

57 rows

Recorded power

73 hp

Recorded weight

4100 kg

Transmissions

8-speed gear

Production years

1974-1976

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerCountyReference

Row-Crop tractorReference

Built in Fleet, EnglandReference

Four-wheel driveReference

Differential lockmechanical front and rearReference

Power steeringReference

Wet disc brakesReference

Open operator station. Cab available.Reference

Engine

Ford 4.2L 4-cyl dieselReference

Engine57.4 kWReference

Ford 256DFReference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.2 LReference

Bore/Stroke112 x 107 mmReference

Power57.4 kWReference

Fuel systemdirect injectionReference

Rated RPM2100Reference

Torque285.0 NmReference

Torque RPM1300Reference

StarterelectricReference

Starter volts12Reference

Oil capacity9.5 LReference

Coolant capacity14.5 LReference

Transmission

8-speed gearReference

TypegearReference

Gears8 forward and 2 reverseReference

Clutch330mm dry discReference

Oil capacity10.4 LReference

PTO & Hydraulics

PTO (claimed)54.4 kWReference

Total flow34.8 lpmReference

Steering cap.2.3 LReference

Rear TypeIIReference

Rear lift2150 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@1900Reference

Capacities

Fuel75.3 LReference

Steering2.3 LReference

Dimensions

Wheelbase181 cmReference

Weight4100 kgReference

Front tire13.6/12-38Reference

Rear tire13.6/12-38Reference

Standard tires (ag)Front: 13.6/12-38. Rear: 13.6/12-38Reference

Optional tires (ag)Front: 23.1/18-26. Rear: 23.1/18-26Reference

Optional tires (ag)Front: 16.9/14-30. Rear: 16.9/14-30Reference

Optional tires (ag)Front: 18.4/15-30. Rear: 18.4/15-30Reference

Optional tires (ag)Front: 16.9/14-34. Rear: 16.9/14-34Reference

Length370 cmReference

Height244 cmReference

Ground clearance39 cmReference

Front tread162/172/182/193/203/213 cmReference

Rear tread162/172/182/193/203/213 cmReference

Electrical

Charging systemalternatorReference

Charging amps46Reference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
