Tractor · 1976Unverified

County 774

Name: County 774
Brand: County

County 774 · 67 hp. Reference specifications; pending source verification.

The County 774 tractor model has a rated power of 67 hp, a mid-range figure for its class. Production of the model occurred from 1976 to 1987. It features a 4-cylinder diesel liquid-cooled engine, paired with four-wheel drive and an 8-speed gearbox. The tractor's listed operating weight is 4662 kg, and it is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

67 hp

Weight

4662 kg

Catalogue coverage

Variants represented

Richest spec table

74 rows

Recorded power

67 hp

Recorded weight

4662 kg

Transmissions

8-speed gear

Production years

1976-1987

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerCountyReference

Built in Fleet, EnglandReference

Four-wheel driveReference

Final drivesplanetaryReference

Power steeringReference

Wet disc brakesReference

Cab standardReference

Engine

Ford 4.2L 4-cyl dieselReference

Ford 4.4L 4-cyl dieselReference

Fuel tank139.7 LReference

Engine61.1 kWReference

Ford 256DFReference

dieselReference

4-cylinderReference

liquid-cooled inlineReference

Displacement4.2 LReference

Bore/Stroke112 x 107 mmReference

Power57.4 kWReference

Air cleaneroil bathReference

Compression16.3:1Reference

Rated RPM2100Reference

Torque284.8 NmReference

Torque RPM1300Reference

StarterelectricReference

Starter volts12Reference

Oil capacity8.5 LReference

Coolant capacity14.5 LReference

FordReference

liquid-cooledReference

Displacement4.4 LReference

Bore/Stroke112 x 112 mmReference

Power61.1 kWReference

Torque298.0 NmReference

Torque RPM1600Reference

Transmission

8-speed gearReference

8-speedReference

TypegearReference

Gears8 forward and 2 reverseReference

Clutch330mm dry discReference

Gears8 forward and 4 reverseReference

PTO & Hydraulics

PTO (claimed)50.0 kWReference

Pressure172.4 barReference

Total flow34.8 lpmReference

Total flow36.7 lpmReference

Steering flow10.6 lpmReference

Steering press.75.8 barReference

Rear lift2086 kgReference

Rear PTOindependentReference

Clutchhydraulic wet discReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@1900Reference

Dimensions

Wheelbase181 cmReference

Weight4662 kgReference

Front tire13.6/12-38Reference

Rear tire13.6/12-38Reference

Standard tires (ag)Front: 13.6/12-38. Rear: 13.6/12-38Reference

Optional tires (ag)Front: 16.9/14-30. Rear: 16.9/14-30Reference

Optional tires (ag)Front: 18.4/15-30. Rear: 18.4/15-30Reference

Optional tires (ag)Front: 16.9/14-34. Rear: 16.9/14-30Reference

Optional tires (ag)Front: 23.1/18-26. Rear: 23.1/18-26Reference

Length370 cmReference

Height (cab)277 cmReference

Height (exhaust)278 cmReference

Ground clearance39 cmReference

Front tread162 to 213 cmReference

Rear tread162 to 213 cmReference

4662 kgReference

Max Drawbar1043 kgReference

Max Drawbar2721 kgReference

Electrical

Charging systemalternatorReference

Charging amps46Reference

Battery volts12Reference

Battery AH128Reference

Speeds

With 13.6/12-38 tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
