Tractor · 1971Unverified
County 944
County 944 — Four-wheel Drive (4WD) tractor · 95 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
95 hp
Weight
4009 kg
Hover a source tag to verify
Overview
ManufacturerCountyReference
Four-wheel Drive (4WD) tractorReference
Built in Fleet, EnglandReference
Drive4x4 4WDReference
Differential lockmechanical four-wheelReference
Power steeringReference
Wet disc brakesReference
Cab standard.Reference
Engine
Ford 4.2L 4-cyl dieselReference
Fuel tank75.3 LReference
Engine70.8 kWReference
Ford 256Reference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.2 LReference
Bore/Stroke112 x 107 mmReference
Power70.8 kWReference
Compression16.5:1Reference
Rated RPM2100Reference
Torque324.1 NmReference
Torque RPM1600Reference
StarterelectricReference
Starter volts12Reference
Oil capacity9.5 LReference
Coolant capacity14.5 LReference
Transmission
8-speedReference
Gears8 forward and 2 reverseReference
Clutch330mm dry discReference
PTO & Hydraulics
Typeopen centerReference
Total flow22.7 lpmReference
Steering flow15.1 lpmReference
Steering press.75.8 barReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift2400 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@1900Reference
Dimensions
Wheelbase181 cmReference
Weight4009 kgReference
Front tire13.6/12-38Reference
Rear tire13.6/12-38Reference
Ag front13.6/12-38Reference
Ag rear13.6/12-38Reference
Ag front23.1/18-26Reference
Ag front16.9/14-3018.4/15-30Reference
Ag front14.9/14-34Reference
Ag rear23.1/18-26Reference
Ag rear16.9/14-3018.4/15-30Reference
Ag rear14.9/14-34Reference
Length370 cmReference
Height (cab)243 cmReference
Ground clearance39 cmReference
Front tread152 to 213 cmReference
Rear tread152 to 213 cmReference
Electrical
Charging systemgeneratorReference
Charging amps22Reference
Battery volts12Reference
Speeds
With 13.6/12-38 tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
