Lawn Tractor · 1959Unverified
Craftsman 123.8837
Craftsman 123.8837 — Riding lawn mower · 5 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
5 hp
Weight
113 kg
Hover a source tag to verify
Overview
DistributorCraftsman (a part of Sears)Reference
ManufacturerYardmanReference
Riding lawn mowerReference
Built in Jackson, Michigan, USAReference
Original price was $325 in 1959Reference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Variants
8850recoil startReference
8837electric startReference
Engine
4.5HP Lauson 221cc 1-cyl gasolineReference
LausonReference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement13.53 ciReference
Bore/Stroke67 x 57 mmReference
Power (gross)3.4 kWReference
Starter typeelectricReference
Transmission
5-speed friction discReference
Typefriction discReference
Gears5 forward and 2 reverseReference
Dimensions
Weight113 kgReference
Shipping weight113 kgReference
Craftsman 123.8837 attachments
26" mid-mount mower deckReference
Electrical
GroundnegativeReference
Battery volts12Reference
26" Mower deck
Typemid-mount CraftsmanReference
Type1-bladeReference
Cutting width66 cmReference
Cut height3 to 9 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
