Lawn Tractor · 1966Unverified

Craftsman 131.8450

Name: Craftsman 131.8450
Brand: Craftsman

Craftsman 131.8450 — Lawn tractor · 6 hp. Reference specifications; pending source verification.

The Craftsman 131.8450 is a lawn tractor with a rated output of 6 hp, making it a compact option in its class. Produced in 1966, it features a 1-cylinder petrol air-cooled engine and a two-wheel drive system with a 3-speed gearbox. The listed weight of the 131.8450 is 165 kg, and it is designed for use on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

6 hp

Weight

165 kg

Catalogue coverage

Variants represented

Richest spec table

45 rows

Recorded power

6 hp

Transmissions

3-speed gear

Production years

1966-1966

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

DistributorCraftsman (a part of Sears)Reference

ManufacturerRoperReference

Lawn tractorReference

Original price was $420 in 1966Reference

Two-wheel driveReference

Manual steeringReference

Open operator station.Reference

Variants

131.8450electric startReference

131.8440recoil startReference

Engine

6HP Techumseh 221cc 1-cyl gasolineReference

Techumseh HM60Reference

gasolineReference

1-cylinderReference

air-cooled horizontal-shaftReference

Displacement13.53 ciReference

Bore/Stroke64 x 67 mmReference

Power (gross)4.5 kWReference

StarterelectricReference

Starter volts12Reference

Sparkplug gap0.762 mmReference

Intake valve clearance0.254 mmReference

Exhaust valve clearance0.254 mmReference

Transmission

3-speed gearReference

TypegearReference

Gears3 forward and 1 reverseReference

1Clutch/brakeReference

2ThrottleReference

3Gear shiftReference

Dimensions

Weight165 kgReference

Front tire12.50x3.75Reference

Rear tire16x5.25Reference

Lawn/turf front12.50x3.75Reference

Lawn/turf rear16x5.25Reference

Shipping weight165 kgReference

Craftsman 131.8450 attachments

32" mid-mount mower deckReference

36" mid-mount mower deckReference

snowblowerReference

bladeReference

Electrical

GroundnegativeReference

Charging systemstarter-generatorReference

Battery volts12Reference

Attachment overview

32" mid-mount mower deckReference

36" mid-mount mower deckReference

SnowblowerReference

BladeReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
