The Craftsman 247.27047 is a lawn tractor with a rated output of 26 hp, categorising it within the higher-powered machines in its class. It was manufactured in 2017. The machine is equipped with a 2-cylinder petrol air-cooled engine, transmitting power through a two-wheel drive system with a hydrostatic transmission. Its listed weight is 340 kg, and it is suited for tasks involving areas of up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
26 hp
Weight
340 kg
Catalogue coverage
Variants represented
2
Richest spec table
43 rows
Recorded power
26 hp
Recorded weight
340 kg
Transmissions
hydrostatic
Production years
2017-2017
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
DistributorCraftsman (a part of Sears)Reference
ManufacturerMTDReference
Garden tractorReference
Original price was $4,000 in 2017Reference
Two-wheel driveReference
Power steeringReference
Open operator station.Reference
Engine
26HP Kohler 747cc 2-cyl gasolineReference
Fuel tank11.4 LReference
KohlerReference
gasolineReference
2-cylinderReference
air-cooled vertical-shaft V-TwinReference
Displacement45.6 ciReference
Power (gross)19.4 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TransmissionTuff Torq K57Reference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchelectricReference
Dimensions
Wheelbase101 cmReference
Weight340 kgReference
Front tire16x6.5Reference
Rear tire22x9.5Reference
Lawn/turf front16x6.5Reference
Lawn/turf rear22x9.5Reference
Length187 cmReference
Height119 cmReference
Front axleCast-ironReference
Craftsman 247.27047 attachments
54" mid-mount mower deckReference
bladeReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
54" mid-mount mower deckReference
BladeReference
54" Mower deck
Typemid-mount CraftsmanReference
Type3-blade with manual liftReference
Cutting width137 cmReference
Cut height3 to 10 cmReference
Cut positions12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
