The Craftsman 502.27021 is a lawn tractor with a rated power output of 14 hp, a mid-range figure for its class. It was manufactured in 2001 and is equipped with a 1-cylinder petrol air-cooled engine, paired with two-wheel drive and a 5-speed gearbox. This model is suitable for operations covering up to 200 acres. Technical specifications for both the UK and US markets are available.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
14 hp
Catalogue coverage
Variants represented
2
Richest spec table
38 rows
Recorded power
14 hp
Transmissions
5-speed gear
Production years
2001-2001
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
DistributorCraftsman (a part of Sears)Reference
ManufacturerMurrayReference
Riding lawn mowerReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
13.5HP Tecumseh 357cc 1-cyl gasolineReference
Fuel tank3.8 LReference
TecumsehReference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement21.82 ciReference
Bore/Stroke84 x 64 mmReference
Power10.1 kWReference
StarterelectricReference
Starter volts12Reference
Oil capacity0.9 LReference
Oil change50 hReference
SparkplugChampion RJ4CReference
Sparkplug gap0.762 mmReference
Transmission
5-speed gearReference
TransmissionDana 4450Reference
Typebelt-driven gearReference
Gears5 forward and 1 reverseReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchmanualReference
Dimensions
Rear tire16x6.5Reference
Lawn/turf rear16x6.5Reference
Craftsman 502.27021 attachments
30" mid-mount mower deckReference
Electrical
GroundnegativeReference
Charging amps3Reference
Battery volts12Reference
30" Mower deck
Typemid-mount CraftsmanReference
Type1-blade with manual liftReference
Cutting width76 cmReference
Cut height3 to 10 cmReference
Cut positions8Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
