Lawn Tractor · 1999Unverified

Craftsman 917.27043

Name: Craftsman 917.27043
Brand: Craftsman

Craftsman 917.27043 — Lawn tractor · 14 hp. Reference specifications; pending source verification.

The Craftsman 917.27043 is a lawn tractor model with a rated output of 14 hp, positioning it centrally within its class in terms of power. This model was manufactured in 1999 and features a 1-cylinder petrol air-cooled engine, connected to a two-wheel drive system via a 5-speed gearbox. It is designed for use on areas up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

14 hp

Catalogue coverage

Variants represented

Richest spec table

39 rows

Recorded power

14 hp

Transmissions

5-speed gear

Production years

1999-1999

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

DistributorCraftsman (a part of Sears)Reference

ManufacturerAYPReference

Lawn tractorReference

Two-wheel driveReference

Manual steeringReference

Open operator station.Reference

Engine

13.5HP Briggs & Stratton 465cc 1-cyl gasolineReference

Fuel tank4.7 LReference

Briggs & Stratton 28R707Reference

gasolineReference

1-cylinderReference

air-cooled vertical-shaftReference

Displacement28.4 ciReference

Bore/Stroke87 x 78 mmReference

Power10.1 kWReference

StarterelectricReference

Starter volts12Reference

SparkplugChampion RJ19LMReference

Sparkplug gap0.762 mmReference

Oil capacity1.4 LReference

Transmission

5-speed gearReference

TransmissionPeerless 205-544CReference

Typebelt-driven gearReference

Gears5 forward and 1 reverseReference

Dimensions

Front tire16x6.0-6Reference

Rear tire18x8.50-8Reference

Lawn/turf front16x6.0-6Reference

Lawn/turf rear18x8.50-8Reference

Craftsman 917.27043 attachments

38" mid-mount mower deckReference

Electrical

GroundnegativeReference

Charging amps3 (charging)Reference

Charging amps5 (headlights)Reference

Battery CCA190Reference

Battery volts12Reference

Battery AH25Reference

Battery GroupU1RReference

38" Mower deck

Typemid-mount CraftsmanReference

Type2-bladeReference

Cutting width96 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
