Lawn Tractor · 2000Unverified
Craftsman 917.27053
Craftsman 917.27053 — Lawn tractor · 15 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
15 hp
Hover a source tag to verify
Overview
DistributorCraftsman (a part of Sears)Reference
ManufacturerAYPReference
Lawn tractorReference
Original price was $1,000 in 2000Reference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
14.5HP Briggs & Stratton 465cc 1-cyl gasolineReference
Fuel tank4.7 LReference
Briggs & Stratton 287707Reference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement28.4 ciReference
Bore/Stroke87 x 78 mmReference
Power (gross)10.8 kWReference
StarterelectricReference
Starter volts12Reference
SparkplugChampion RC12YCReference
Sparkplug gap0.762 mmReference
Oil capacity1.4 LReference
Oil change25 hReference
Transmission
6-speed gearReference
TransmissionDana 4360-140Reference
Typebelt-driven gearReference
Gears6 forward and 1 reverseReference
Oil changesealed unit, owner service is not recommendedReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchmanualReference
Mid PTO TypepulleyReference
Dimensions
Front tire15x6.0-6Reference
Rear tire18x9.5-8Reference
Lawn/turf front15x6.0-6Reference
Lawn/turf rear18x9.5-8Reference
Craftsman 917.27053 attachments
42" mid-mount mower deckReference
Electrical
GroundnegativeReference
Charging amps9Reference
Battery CCA190Reference
Battery volts12Reference
Battery GroupU1RReference
42" Mower deck
Typemid-mount CraftsmanReference
Type2-blade with manual liftReference
Cutting width106 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
