Lawn Tractor · 2004Unverified

Craftsman 917.27361

Name: Craftsman 917.27361
Brand: Craftsman

Craftsman 917.27361 — DYT 4000 Series · 24 hp. Reference specifications; pending source verification.

The Craftsman 917.27361 is a lawn tractor model rated at approximately 24 hp, positioning it at the more powerful end of its class. Manufactured in 2004, it features a 2-cylinder petrol air-cooled engine, coupled with two-wheel drive and a 6-speed gearbox. This model is suitable for operations covering up to 200 acres. Specifications for the UK and US markets are listed.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

24 hp

Catalogue coverage

Variants represented

Richest spec table

42 rows

Recorded power

24 hp

Transmissions

6-speed gear

Production years

2004-2004

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

DistributorCraftsman (a part of Sears)Reference

ManufacturerAYPReference

Lawn tractorReference

Two-wheel driveReference

Manual steeringReference

Open operator stationReference

Engine

24HP Briggs & Stratton 724cc 2-cyl gasolineReference

Fuel tank15.1 LReference

Briggs & Stratton 445777Reference

gasolineReference

2-cylinderReference

air-cooled vertical-shaft V-TwinReference

Displacement44.2 ciReference

Bore/Stroke79 x 73 mmReference

Power (gross)17.9 kWReference

StarterelectricReference

Starter volts12Reference

SparkplugChampion QC12YCReference

Sparkplug gap1.016 mmReference

Oil capacity1.9 LReference

Transmission

6-speed gearReference

TransmissionPeerless 206-545cReference

Typebelt-driven gearReference

Gears6 forward and 1 reverseReference

PTO & Hydraulics

Mid PTOindependentReference

ClutchelectricReference

Dimensions

Front tire15x6.0-6Reference

Rear tire20x10.8Reference

Lawn/turf front15x6.0-6Reference

Lawn/turf rear20x10.8Reference

Craftsman 917.27361 attachments

48" mid-mount mower deckReference

Electrical

GroundnegativeReference

Charging amps15Reference

Battery CCA280Reference

Battery volts12Reference

Battery AH35Reference

Battery GroupU1RReference

48" Mower deck

Typemid-mount CraftsmanReference

Type3-blade with manual liftReference

Cutting width121 cmReference

BeltAYP 174368 (primary)Reference

BeltAYP 180808 (secondary)Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
