Lawn Tractor · 2014Unverified
Craftsman Professional 917.20417 Z7400
Craftsman Professional 917.20417 Z7400 — Z7000 Series · 26 hp. Reference specifications; pending source verification.
The Craftsman Professional 917.20417 Z7400 is a lawn tractor with an engine output of 26 hp, categorising it as a higher-powered machine in its class. Manufactured in 2014, this model features a 2-cylinder petrol air-cooled engine, which powers a two-wheel drive system with a hydrostatic transmission. The machine weighs approximately 317 kg and is suitable for tasks involving up to 200 acres of land.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
26 hp
Weight
317 kg
Catalogue coverage
Variants represented
2
Richest spec table
47 rows
Recorded power
26 hp
Recorded weight
317 kg
Transmissions
hydrostatic
Production years
2014-2014
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
DistributorCraftsman Professional (a part of Sears)Reference
ManufacturerHusqvarnaReference
Zero-turn mowerReference
Original price was $5300 in 2014Reference
Two-wheel driveReference
Steeringdifferential hydrostaticReference
Open operator station.Reference
Engine
26HP Kohler 747cc 2-cyl gasolineReference
Fuel tank18.9 LReference
Kohler KT-745Reference
gasolineReference
2-cylinder 4-valveReference
air-cooled vertical-shaft V-TwinReference
Displacement45.6 ciReference
Bore/Stroke84 x 69 mmReference
Power (gross)19.4 kWReference
StarterelectricReference
Starter volts12Reference
Oil change100 hReference
Transmission
hydrostaticReference
TransmissionHydro Gear ZT-3100Reference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
Oil capacity1.9 LReference
Oil type20W50Reference
Oil change200 hReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchElectricReference
Dimensions
Wheelbase127 cmReference
Weight317 kgReference
Front tire13x6.5x5Reference
Rear tire22x9.5Reference
Lawn/turf front13x6.5x5Reference
Lawn/turf rear22x9.5Reference
Length191 cmReference
Width124 cmReference
Height106 cmReference
Front axleCaster wheelsReference
Craftsman Professional 917.20417 attachments
54" mid-mount mower deckReference
Electrical
GroundnegativeReference
Charging amps15Reference
Battery volts12Reference
54" Mower deck
Typemid-mount CraftsmanReference
Type3-blade with Manual liftReference
Cutting width137 cmReference
Overall width171 cmReference
Cut height3 to 11 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
