Lawn Tractor · 2008Unverified

Craftsman Professional 917.28874

Craftsman Professional 917.28874 — Garden tractor · 27 hp. Reference specifications; pending source verification.

The Craftsman Professional 917.28874 is a lawn tractor model with a rated power of 27 hp, positioning it at the higher end of its class in terms of power. Built in 2008, this model features a 2-cylinder petrol air-cooled engine, paired with a two-wheel drive system and hydrostatic transmission. The operating weight of the Craftsman Professional 917.28874 is 278 kg, and it is designed for use on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power
27 hp
Weight
278 kg

Catalogue coverage

Variants represented
2
Richest spec table
43 rows
Recorded power
27 hp
Recorded weight
278 kg
Transmissions
hydrostatic
Production years
2008-2008
Verified variants
0

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

DistributorCraftsman Professional (a part of Sears)Reference
ManufacturerHusqvarnaReference
Garden tractorReference
Two-wheel driveReference
Manual steeringReference
Mechanical disc brakesReference
Open operator station. Adjustable seat with arm-rests and cup holder.Reference

Engine

27HP Kohler 725cc 2-cyl gasolineReference
Fuel tank15.1 LReference
Kohler SV740Reference
gasolineReference
2-cylinderReference
air-cooled vertical-shaft V-TwinReference
Displacement44.24 ciReference
Power (gross)20.1 kWReference
Air cleanerdual paper elementsReference
StarterelectricReference
Starter volts12Reference
SparkplugChampion RC12YCReference
Sparkplug gap7.620 mmReference
Oil capacity1.9 LReference

Transmission

hydrostaticReference
TransmissionTuff Torq K66Reference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference

Dimensions

Weight278 kgReference
Front tire16x6.5-6Reference
Rear tire23x10.5-8Reference
Lawn/turf front16x6.5-6Reference
Lawn/turf rear23x10.5-8Reference

Craftsman Professional 917.28874 attachments

54" mid-mount mower deckReference

Electrical

GroundnegativeReference
Charging amps15Reference
Battery CCA280Reference
Battery volts12Reference
Battery AH35Reference
Battery GroupU1RReference

Attachment overview

Optional three-bin bagger (24896).Reference

54" Mower deck

Typemid-mount CraftsmanReference
Type3-blade with manual liftReference
Cutting width137 cmReference
Cut height3 to 10 cmReference
Cut positions7Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
