The Craftsman R105 is a lawn tractor, manufactured from 2019 to 2021. It features a 1-cylinder petrol air-cooled engine and a two-wheel drive system with a 6-speed gearbox. The operating weight of the model is listed at 149 kg. Specifications for the Craftsman R105 are provided in both metric and imperial units.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Weight
149 kg
Catalogue coverage
Variants represented
2
Richest spec table
32 rows
Transmissions
6-speed gear
Production years
2019-2021
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
DistributorCraftsman (a part of Stanley)Reference
ManufacturerMTDReference
Riding lawn mowerReference
Built in Willard, Ohio, USAReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
Chongqing Zongshen 382cc 1-cyl gasolineReference
Fuel tank4.9 LReference
Chongqing Zongshen 7T84JUAReference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement23.31 ciReference
StarterelectricReference
Starter volts12Reference
Transmission
6-speed gearReference
Typebelt-driven gearReference
Gears6 forward and reverseReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchmanualReference
Dimensions
Weight149 kgReference
Front tire13x5-6Reference
Rear tire16x6.5-8Reference
Lawn/turf front13x5-6Reference
Lawn/turf rear16x6.5-8Reference
Craftsman R105 attachments
30" mid-mount mower deckReference
Electrical
GroundnegativeReference
Battery volts12Reference
30" Mower deck
Typemid-mount CraftsmanReference
Type1-blade with manual liftReference
Cutting width76 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
