Lawn Tractor · 2019Unverified
Craftsman T105 CMXGRAM7821242
Craftsman T105 CMXGRAM7821242 — Lawn tractor · 10 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
10 hp
Weight
231 kg
Hover a source tag to verify
Overview
DistributorCraftsman (a part of Stanley)Reference
ManufacturerMTDReference
Lawn tractorReference
Built in Willard, Ohio, USAReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
9.5HP Chongqing Zongshen 439cc 1-cyl gasolineReference
Fuel tank4.9 LReference
Chongqing Zongshen 7T90HUReference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement26.79 ciReference
Bore/Stroke90 x 66 mmReference
Power7.1 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
7-speed CVTReference
Typebelt-driven CVTReference
Gears7 forward and reverseReference
1Clutch/BrakeReference
2ThrottleReference
3Speed set/parking brakeReference
4Forward/reverseReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchmanualReference
Dimensions
Weight231 kgReference
Front tire15x6-6Reference
Rear tire20x8-8Reference
Lawn/turf front15x6-6Reference
Lawn/turf rear20x8-8Reference
Craftsman T105 attachments
42" mid-mount mower deckReference
snowblowerReference
bladeReference
T105 Serial Number Location
Serial number decal on the bottom of the seat mounting bracket.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
42" mid-mount mower deckReference
SnowblowerReference
BladeReference
42" Mower deck
Typemid-mount CraftsmanReference
Type2-blade with manual liftReference
Cutting width106 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
