Lawn Tractor · 2020Unverified
Craftsman T85
Craftsman T85 — Lawn tractor · 9 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
9 hp
Hover a source tag to verify
Overview
DistributorCraftsman (a part of Stanley)Reference
ManufacturerMTDReference
Lawn tractorReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
8.5HP Chongqing Zongshen 381cc 1-cyl gasolineReference
Chongqing Zongshen 7T84Reference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement23.3 ciReference
Power (gross)6.3 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
7-speed CVTReference
TransmissionMTDReference
Typebelt-driven CVTReference
Gears7 forward and 1 reverseReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchmanualReference
Dimensions
Front tire15x6-6Reference
Rear tire20x8-8Reference
Lawn/turf front15x6-6Reference
Lawn/turf rear20x8-8Reference
Craftsman T85 attachments
36" mid-mount mower deckReference
Electrical
GroundnegativeReference
Battery volts12Reference
36" Mower deck
Typemid-mount CraftsmanReference
Type2-blade with manual liftReference
Cutting width91 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
