Lawn Tractor · 1963Unverified
Cub Cadet 100
Cub Cadet 100 — Garden tractor · 10 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
10 hp
Weight
281 kg
Hover a source tag to verify
Overview
ManufacturerCub Cadet (a part of International Harvester)Reference
Garden tractorReference
Built in Louisville, Kentucky, USAReference
Two-wheel driveReference
Manual steeringReference
Dry disc brakesReference
Open operator station.Reference
Engine
10HP Kohler 391cc 1-cyl gasolineReference
Fuel tank6.2 LReference
Kohler K-241Reference
gasolineReference
1-cylinderReference
air-cooledReference
Displacement23.9 ciReference
Bore/Stroke83 x 73 mmReference
Power (gross)7.5 kWReference
Rated RPM3600Reference
Starter volts12Reference
Transmission
3-speed gearReference
6-speed creeperReference
Typeshaft-driven gearReference
Gears3 forward and 1 reverseReference
Clutchdry discReference
TypecreeperReference
Gears6 forward and 2 reverseReference
PTO & Hydraulics
Rear PTOtransmissionReference
Dimensions
Wheelbase109 cmReference
Weight281 kgReference
Front tire4.80x4.00-8Reference
Rear tire6-12Reference
Lawn/turf front4.80x4.00-8Reference
Lawn/turf rear6-12Reference
Lawn/turf front16x6.50-8Reference
Lawn/turf rear8-12Reference
Length160 cmReference
Width84 cmReference
Height (steering wheel)101 cmReference
Shipping weight281 kgReference
Ground clearance15 cmReference
Front tread68 cmReference
Rear tread68 cmReference
Cub Cadet 100 attachments
38" mid-mount mower deckReference
42" mid-mount mower deckReference
48" mid-mount mower deckReference
snowblowerReference
100 Serial Number Location
Serial number stamped into the right side of transmission below frame rail.Reference
100 Serial Numbers
196365458Reference
196473875Reference
1965104307Reference
Final127160Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemgeneratorReference
Battery volts12Reference
Attachment overview
38" mid-mount mower deckReference
42" mid-mount mower deckReference
48" mid-mount mower deckReference
SnowblowerReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
