Lawn Tractor · 1978Unverified

Cub Cadet 111

Cub Cadet 111 — Lawn tractor · 11 hp. Reference specifications; pending source verification.

The Cub Cadet 111 is a lawn tractor with a rated power of 11 hp, a mid-range figure for its class. It was manufactured between 1978 and 1979. The 111 is equipped with a 1-cylinder petrol air-cooled engine, paired with two-wheel drive and a 3-speed gearbox. It has an operating weight of 195 kg and is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power
11 hp
Weight
195 kg

Catalogue coverage

Variants represented
2
Richest spec table
35 rows
Recorded power
11 hp
Transmissions
3-speed gear
Production years
1978-1979
Verified variants
0

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerCub Cadet (a part of International Harvester)Reference
Lawn tractorReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference

Engine

11HP Briggs & Stratton 399cc 1-cyl gasolineReference
Fuel tank3.8 LReference
Briggs & StrattonReference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement24.36 ciReference
Bore/Stroke87 x 60 mmReference
Power (gross)8.2 kWReference
StarterelectricReference
Starter volts12Reference
Image courtesy of Terry StephenReference

Transmission

3-speed gearReference
TransmissionPeerlessReference
Typebelt-driven gearReference
Gears3 forward and 1 reverseReference

Dimensions

Wheelbase109 cmReference
Weight195 kgReference
Front tire13x5.00-6Reference
Rear tire18x9.50-8Reference
Lawn/turf front13x5.00-6Reference
Lawn/turf rear18x9.50-8Reference
Length154 cmReference
Shipping weight195 kgReference

Cub Cadet 111 attachments

36" mid-mount mower deckReference

Electrical

GroundnegativeReference
Battery volts12Reference

36" Mower deck

Typemid-mount Cub CadetReference
Type2-blade with manual liftReference
Cutting width91 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
