Lawn Tractor · 1978Unverified
Cub Cadet 111
Cub Cadet 111 — Lawn tractor · 11 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
11 hp
Weight
195 kg
Hover a source tag to verify
Overview
ManufacturerCub Cadet (a part of International Harvester)Reference
Lawn tractorReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
11HP Briggs & Stratton 399cc 1-cyl gasolineReference
Fuel tank3.8 LReference
Briggs & StrattonReference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement24.36 ciReference
Bore/Stroke87 x 60 mmReference
Power (gross)8.2 kWReference
StarterelectricReference
Starter volts12Reference
Image courtesy of Terry StephenReference
Transmission
3-speed gearReference
TransmissionPeerlessReference
Typebelt-driven gearReference
Gears3 forward and 1 reverseReference
Dimensions
Wheelbase109 cmReference
Weight195 kgReference
Front tire13x5.00-6Reference
Rear tire18x9.50-8Reference
Lawn/turf front13x5.00-6Reference
Lawn/turf rear18x9.50-8Reference
Length154 cmReference
Shipping weight195 kgReference
Cub Cadet 111 attachments
36" mid-mount mower deckReference
Electrical
GroundnegativeReference
Battery volts12Reference
36" Mower deck
Typemid-mount Cub CadetReference
Type2-blade with manual liftReference
Cutting width91 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
