Lawn Tractor · 1967Unverified
Cub Cadet 124
Cub Cadet 124 — 1X4/1X5 Series · 12 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
12 hp
Weight
285 kg
Hover a source tag to verify
Overview
ManufacturerCub Cadet (a part of International Harvester)Reference
Garden tractorReference
Built in Louisville, Kentucky, USAReference
Two-wheel driveReference
SteeringmanualReference
Dry disc brakesReference
Open operator station with vinyl-padded fiberglass seat.Reference
Engine
12HP Kohler 479cc 1-cyl gasolineReference
Fuel tank7.6 LReference
Kohler K301ASReference
gasolineReference
1-cylinderReference
air-cooledReference
Displacement29.25 ciReference
Bore/Stroke86 x 83 mmReference
Power8.9 kWReference
Rated RPM3600Reference
Idle RPM1000-3800Reference
Starter volts12Reference
SparkplugChampion H-10Reference
Sparkplug gap0.635 mmReference
Point gap0.508 mmReference
Intake valve clearance0.254 mmReference
Exhaust valve clearance0.508 mmReference
Oil capacity1.4 LReference
Oil change30 hReference
Transmission
3-speed gearReference
6-speed creeperReference
Typeshaft-driven gearReference
Gears3 forward and 1 reverseReference
Clutch4.5-inch dry discReference
Oil capacity3.3 LReference
Three-speed transmission operated by gear shift lever and combination clutch/brake pedal. Tractor must be stopped, and clutch used, to shift.Reference
TypecreeperReference
Gears6 forward and 2 reverseReference
Optional creeper adds an additional low range to the base transmission. Creeper drive is engaged when creeper shift lever is pulled to the rear.Reference
PTO & Hydraulics
TypeoptionalReference
Pressure27.6 barReference
Pump flow9.5 lpmReference
TypeCub Cadet three-pointReference
Rear PTOtransmissionReference
Clutchdry discReference
Rear PTO Type525Reference
Front PTOindependentReference
ClutchmechanicalReference
Front PTO Type3600Reference
Dimensions
Wheelbase109 cmReference
Weight285 kgReference
Front tire4.80x4.00-8Reference
Rear tire23x8.50-12Reference
Lawn/turf front4.80x4.00-8Reference
Lawn/turf rear23x8.50-12Reference
Length162 cmReference
Width91 cmReference
Height (steering wheel)100 cmReference
Ground clearance15 cmReference
Rear tread68 cmReference
Cub Cadet 124 attachments
38" mid-mount mower deckReference
42" mid-mount mower deckReference
48" mid-mount mower deckReference
snowblowerReference
bladeReference
124 Serial Number Location
Serial number plate mounted on the rear drive housing.Reference
124 Serial Numbers
1967218010Reference
1968225056Reference
1969280840Reference
Final306085Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemgeneratorReference
Charging amps15Reference
Battery volts12Reference
Attachment overview
38" mid-mount mower deckReference
42" mid-mount mower deckReference
48" mid-mount mower deckReference
SnowblowerReference
BladeReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
