Lawn Tractor · 1969Unverified

Cub Cadet 147

Name: Cub Cadet 147
Brand: Cub Cadet

Cub Cadet 147 — 1X6/1X7 Series · 14 hp. Reference specifications; pending source verification.

The Cub Cadet 147 is a lawn tractor rated at approximately 14 hp, a mid-range power output for its category. In production from 1969 to 1971, it features a 1-cylinder petrol air-cooled engine, coupled with two-wheel drive and a hydrostatic transmission. Its operating weight is listed as 335 kg, with a capacity for operations of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

14 hp

Weight

335 kg

Catalogue coverage

Variants represented

Richest spec table

74 rows

Recorded power

14 hp

Recorded weight

335 kg

Transmissions

hydrostatic

Production years

1969-1971

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerCub Cadet (a part of International Harvester)Reference

Garden tractorReference

Built in Louisville, Kentucky, USAReference

Two-wheel driveReference

SteeringmanualReference

Mechanical disc brakesReference

Open operator station with padded seat.Reference

Engine

14HP Kohler 512cc 1-cyl gasolineReference

Fuel tank7.6 LReference

Kohler K321AReference

gasolineReference

1-cylinderReference

air-cooledReference

Displacement31.27 ciReference

Bore/Stroke89 x 83 mmReference

Power10.4 kWReference

Air cleanerdryReference

Compression6:1Reference

Rated RPM3600Reference

Idle RPM1000-3800Reference

Torque31.9 NmReference

Torque RPM2200Reference

Starter volts12Reference

SparkplugChampion H-10Reference

Sparkplug gap0.635 mmReference

Point gap0.508 mmReference

Intake valve clearance0.254 mmReference

Exhaust valve clearance0.508 mmReference

Oil capacity1.4 LReference

Transmission

hydrostaticReference

TypehydrostaticReference

Gearsinfinite forward and reverseReference

Oil capacity6.6 LReference

Oil typeIH Hy-TranReference

PTO & Hydraulics

TypeCub Cadet three-pointReference

Clutchmechanical dry discReference

Front PTO Type3600Reference

Dimensions

Wheelbase109 cmReference

Weight335 kgReference

Front tire16x6.50-8Reference

Rear tire23x8.50-12Reference

Lawn/turf front16x6.50-8Reference

Lawn/turf rear23x8.50-12Reference

Length162 cmReference

Width83 cmReference

Height (steering wheel)100 cmReference

Shipping weight335 kgReference

Ground clearance15 cmReference

Front axleCast-ironReference

Flange rear axleReference

Front tread68 cmReference

Rear tread68 cmReference

Cub Cadet 147 attachments

38" mid-mount mower deckReference

42" mid-mount mower deckReference

48" mid-mount mower deckReference

snowblowerReference

bladeReference

front-end loaderReference

147 Serial Number Location

Serial plate on rear of tractor.Reference

147 Serial Numbers

1969316816Reference

1970322858Reference

1971373301Reference

Final400000Reference

FAQ: How to read a serial number table.Reference

Electrical

GroundnegativeReference

Charging systemgeneratorReference

Charging amps15Reference

Battery volts12Reference

Attachment overview

38" mid-mount mower deckReference

42" mid-mount mower deckReference

48" mid-mount mower deckReference

SnowblowerReference

BladeReference

Front-end loaderReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
