The Cub Cadet 2146 is a lawn tractor with a rated power output of 14 hp, placing it in the middle of its class. Manufactured between 2000 and 2001, it features a 1-cylinder petrol air-cooled engine, transmitting power to the two-wheel drive via a hydrostatic transmission. The listed weight of the Cub Cadet 2146 is 322 kg, and its intended application is for areas of up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
14 hp
Weight
322 kg
Catalogue coverage
Variants represented
2
Richest spec table
55 rows
Recorded power
14 hp
Recorded weight
322 kg
Transmissions
hydrostatic
Production years
2000-2001
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerCub Cadet (a part of MTD)Reference
Lawn tractorReference
Original price was $2,900 in 2000Reference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
14HP Linamar 388cc 1-cyl gasolineReference
Fuel tank8.5 LReference
Linamar ZX390Reference
gasolineReference
1-cylinderReference
air-cooled horizontal-shaftReference
Displacement23.7 ciReference
Bore/Stroke84 x 70 mmReference
Power (gross)10.4 kWReference
Fuel systemcarburetorReference
Air cleanerdryReference
Idle RPM1400-3500Reference
StarterelectricReference
Starter volts12Reference
Oil capacity1.9 LReference
Transmission
hydrostaticReference
Typeshaft-driven hydrostaticReference
Gearsinfinite forward and reverseReference
Oil capacity5.7 LReference
Oil typeCC Drive Fluid PlusReference
Oil change100 hReference
PTO & Hydraulics
Front PTOindependentReference
ClutchelectricReference
Front PTO TypepulleyReference
Dimensions
Wheelbase119 cmReference
Weight322 kgReference
Front tire15x6.5Reference
Rear tire20x9Reference
Lawn/turf front15x6.5Reference
Lawn/turf rear20x9Reference
Length182 cmReference
Height (steering wheel)106 cmReference
Shipping weight322 kgReference
Front axle25 mmReference
Cub Cadet 2146 attachments
38" mid-mount mower deckReference
snowblowerReference
bladeReference
Electrical
GroundnegativeReference
Charging systemflywheel alternatorReference
Charging amps15Reference
Battery CCA275Reference
Battery volts12Reference
Attachment overview
38" mid-mount mower deckReference
SnowblowerReference
BladeReference
38" Mower deck
Typemid-mount Cub Cadet 190-213-100Reference
Type2-blade with manual liftReference
Cutting width96 cmReference
Cut height5 to 10 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
