Lawn Tractor · 1999Unverified
Cub Cadet 2164
Cub Cadet 2164 — Lawn tractor · 16 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
16 hp
Weight
269 kg
Hover a source tag to verify
Overview
ManufacturerCub Cadet (a part of MTD)Reference
Lawn tractorReference
Original price was $3,800 in 2000Reference
Two-wheel driveReference
Manual steeringReference
Mechanical drum brakesReference
Open operator station.Reference
Engine
16HP Vanguard 480cc 2-cyl gasolineReference
Fuel tank11.4 LReference
VanguardReference
gasolineReference
2-cylinderReference
air-cooled horizontal-shaft V-TwinReference
Displacement29.3 ciReference
Bore/Stroke68 x 66 mmReference
Power (gross)11.9 kWReference
Rated RPM3350Reference
Idle RPM1200-3600Reference
StarterelectricReference
Starter volts12Reference
Sparkplug759-3336Reference
Sparkplug gap0.762 mmReference
Intake valve clearance0.127 mmReference
Exhaust valve clearance0.127 mmReference
Oil capacity1.7 LReference
Oil change50 hReference
Image courtesy of Myles M.Reference
Transmission
hydrostaticReference
Typeshaft-driven hydrostaticReference
Gearsinfinite forward and reverseReference
Oil capacity5.7 LReference
PTO & Hydraulics
Front PTOindependentReference
ClutchelectricReference
Front PTO TypepulleyReference
Dimensions
Wheelbase119 cmReference
Weight269 kgReference
Front tire15x6-6Reference
Rear tire20x9-8Reference
Lawn/turf front15x6-6Reference
Lawn/turf rear20x9-8Reference
Length182 cmReference
Width129 cmReference
Height (steering wheel)106 cmReference
Ground clearance15 cmReference
Cub Cadet 2164 attachments
42" mid-mount mower deckReference
snowblowerReference
bladeReference
2164 Serial Number Location
Serial number plate on the left side of the 2164 frame, under the running boards.Reference
Electrical
GroundnegativeReference
Charging systemflywheel alternatorReference
Charging amps15Reference
Battery CCA275Reference
Battery volts12Reference
Attachment overview
42" mid-mount mower deckReference
SnowblowerReference
BladeReference
A 28-inch rear tiller, model 190304, with electric lift was available. A 6.5 bushel twin-bag rear grass catcher (model 190305) was optional.Reference
42" Mower deck
Typemid-mount Cub Cadet 190-214-100Reference
Type2-blade with manual liftReference
Cutting width106 cmReference
Belt954-3055A (PTO)Reference
Belt954-3073 (deck)Reference
Cut height3 to 10 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
