Tractor · 2006Unverified
Cub Cadet 5264
Cub Cadet 5264 — Sub-Compact Utility tractor · 20 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
20 hp
Weight
612 kg
Hover a source tag to verify
Overview
ManufacturerCub CadetReference
Sub-Compact Utility tractorReference
Original price was $9,500 in 2007Reference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
External dual disc brakesReference
Two-post folding ROPS.Reference
Engine
Daihatsu 1.0L 3-cyl dieselReference
Engine19.4 kWReference
DaihatsuReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.0 LReference
Bore/Stroke72 x 78 mmReference
Power19.4 kWReference
Fuel systemmechanicalReference
Rated RPM3600Reference
Idle RPM1500-3600Reference
Starter volts12Reference
Coolant capacity5.0 LReference
Intake valve clearance0.203 mmReference
Exhaust valve clearance0.203 mmReference
Oil capacity3.3 LReference
Oil change150 hReference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
Oil capacity18.9 LReference
Oil typeCub Cadet Drive System Fluid PlusReference
Oil change200 hReference
Two-range hydrostatic transmission with right-hand forward and reverse pedals. Tractor must be stopped to shift ranges.Reference
PTO & Hydraulics
PTO (claimed)14.9 kWReference
Hydraulic system18.9 LReference
Typeopen centerReference
Capacity18.9 LReference
Pressure103.4 barReference
Valves1 (optional)Reference
Total flow20.8 lpmReference
Rear TypeIReference
Rear lift (at ends)464 kgReference
Rear lift (at 24"/610mm)308 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Mid PTOindependentReference
Mid PTO Type2000Reference
Capacities
Fuel21.2 LReference
Dimensions
Wheelbase139 cmReference
Weight612 kgReference
Front tire18x9.5-8Reference
Rear tire26x12-12Reference
Ag front18x9.5-8Reference
Ag rear26x12-12Reference
Lawn/turf front18x8.5-8Reference
Lawn/turf rear26x12-12Reference
Length215 cmReference
Length261 cmReference
Width114 cmReference
Height129 cmReference
Height (ROPS)208 cmReference
Ground clearance12 cmReference
Cub Cadet 5264 attachments
54" mid-mount mower deckReference
60" mid-mount mower deckReference
snowblowerReference
bladeReference
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps40Reference
Battery CCA500Reference
Battery volts12Reference
Attachment overview
54" mid-mount mower deckReference
60" mid-mount mower deckReference
SnowblowerReference
BladeReference
Front-end loaderReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
