Lawn Tractor · 1971Unverified

Cub Cadet 55

Name: Cub Cadet 55
Brand: Cub Cadet

Cub Cadet 55 — Model year 1971-19811982-1983 · 5 hp. Reference specifications; pending source verification.

The Cub Cadet 55 is a lawn tractor with a rated power output of 5 hp, positioning it at the lighter end of its class. It was manufactured between 1971 and 1983. The model features a 1-cylinder petrol air-cooled engine paired with two-wheel drive and a 3-speed gearbox, with an operating weight of 154 kg. It is suitable for use on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

5 hp

Weight

154 kg

Catalogue coverage

Variants represented

Richest spec table

37 rows

Recorded power

5 hp

Transmissions

3-speed gear

Production years

1971-1983

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerCub Cadet (a part of International Harvester)Reference

Riding lawn mowerReference

Built in Memphis, Tennessee, USAReference

Two-wheel driveReference

Manual steeringReference

Open operator station.Reference

Engine

5HP Briggs & Stratton 206cc 1-cyl gasolineReference

Briggs & Stratton 130000Reference

gasolineReference

1-cylinderReference

air-cooled vertical-shaftReference

Displacement12.57 ciReference

Bore/Stroke65 x 62 mmReference

Power (gross)3.7 kWReference

Air cleaneroiled foamReference

Rated RPM3600Reference

Starter typemanual recoilReference

Oil capacity0.5 LReference

Transmission

3-speed gearReference

TypegearReference

Gears3 forward and 1 reverseReference

Dimensions

Wheelbase88 cmReference

Weight154 kgReference

Front tire11x4.00-5Reference

Rear tire13x5.00-6Reference

Lawn/turf front11x4.00-5Reference

Lawn/turf rear13x5.00-6Reference

Length142 cmReference

Cub Cadet 55 attachments

28" mid-mount mower deckReference

bladeReference

Attachment overview

28" mid-mount mower deckReference

BladeReference

28" Mower deck

Typemid-mount Cub CadetReference

Type1-blade with manual liftReference

Cutting width71 cmReference

Cut height3 to 10 cmReference

Cut positions6Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
