Tractor · 2005Unverified
Cub Cadet 6284D
Cub Cadet 6284D — Compact Utility tractor · 21 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
21 hp
Weight
885 kg
Hover a source tag to verify
Overview
ManufacturerCub Cadet (a part of MTD)Reference
Compact Utility tractorReference
Original price was $12,999 in 2007Reference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Expanding dry shoe brakesReference
Two-post folding ROPS.Reference
Engine
Caterpillar 1.1L 3-cyl dieselReference
Fuel tank22.7 LReference
Engine20.9 kWReference
Caterpillar C1.1Reference
dieselReference
3-cylinderReference
liquid-cooled inlineReference
Displacement1.1 LReference
Bore/Stroke77 x 81 mmReference
Power20.9 kWReference
Compression23:1Reference
Rated RPM3400Reference
Idle RPM1400-3400Reference
Torque67.0 NmReference
Torque RPM2400Reference
StarterelectricReference
Starter volts12Reference
Oil capacity4.9 LReference
Coolant capacity5.2 LReference
Intake valve clearance0.203 mmReference
Exhaust valve clearance0.203 mmReference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
PTO & Hydraulics
PTO (claimed)15.7 kWReference
Typeopen centerReference
Pressure103.4 barReference
Valves1Reference
Pump flow18.9 lpmReference
Total flow30.3 lpmReference
Steering flow11.4 lpmReference
Rear TypeIReference
Rear lift (at ends)521 kgReference
Rear lift (at 24"/610mm)430 kgReference
Rear PTOindependentReference
ClutchelectricReference
Rear PTO Type540 (1.375)Reference
Mid PTOindependentReference
Mid PTO Type2000 (1.00)Reference
Dimensions
Wheelbase147 cmReference
Weight885 kgReference
Weight430 kgReference
Lawn/turf front23x9.5Reference
Lawn/turf rear31x12Reference
Industrial front23x8.5Reference
Industrial rear10x16.5Reference
Length231 cmReference
Width127 cmReference
Height208 cmReference
Ground clearance25 cmReference
Cub Cadet 6284D attachments
54" mid-mount mower deckReference
60" mid-mount mower deckReference
snowblowerReference
bladeReference
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps40Reference
Battery CCA500Reference
Battery volts12Reference
Attachment overview
54" mid-mount mower deckReference
60" mid-mount mower deckReference
SnowblowerReference
BladeReference
Front-end loaderReference
BackhoeReference
The mid-mount mowers require the lift kit (590-831-100). The front blade and snow blower require the front hitch kit (590-611-100). The snow blower also requires the front PTO kit (590-624-100).Reference
Cub Cadet 612 Backhoe
Backhoe typeCub Cadet 612 BackhoeReference
Transport height169 cmReference
Bucket width20 cmReference
Bucket width30 cmReference
Bucket width40 cmReference
Bucket width45 cmReference
Bucket width60 cmReference
Digging depth198 cmReference
Reach from pivot238 cmReference
Loading height133 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force877 kgReference
Dipperstick force458 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
