Lawn Tractor · 1965Unverified
Cub Cadet 71
Cub Cadet 71 — 1X2/1X3 Series · 7 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
7 hp
Weight
251 kg
Hover a source tag to verify
Overview
ManufacturerCub Cadet (a part of International Harvester)Reference
Garden tractorReference
Built in Louisville, Kentucky, USAReference
Two-wheel driveReference
Manual steeringReference
Dry disc brakesReference
Open operator station with steel pan seat.Reference
Engine
7HP Kohler 262cc 1-cyl gasolineReference
Fuel tank4.7 LReference
Kohler K161Reference
gasolineReference
1-cylinderReference
air-cooled horizontal-shaftReference
Displacement16 ciReference
Bore/Stroke73 x 64 mmReference
Power (gross)5.2 kWReference
Compression6.2:1Reference
Rated RPM3600Reference
Startermanual recoilReference
StarterelectricReference
Starter volts12Reference
Oil capacity1.1 LReference
Sparkplug gap0.635 mmReference
Point gap0.508 mmReference
Intake valve clearance0.152 mmReference
Exhaust valve clearance0.432 mmReference
Transmission
3-speed gearReference
6-speed creeperReference
Typeshaft-driven gearReference
Gears3 forward and 1 reverseReference
Clutch114.3mm dry discReference
Oil capacity3.3 LReference
TypecreeperReference
Gears6 forward and 2 reverseReference
1Clutch/Brake PedalReference
2ThrottleReference
3Gear ShiftReference
4Range ShiftReference
PTO & Hydraulics
Rear PTOtransmissionReference
Rear PTO TypeCub (0.937 CCW)Reference
Engine RPM515@3600Reference
Front PTOindependentReference
ClutchmechanicalReference
Dimensions
Wheelbase109 cmReference
Weight251 kgReference
Front tire4.80x4.00-8Reference
Rear tire6-12Reference
Lawn/turf front4.80x4.00-8Reference
Lawn/turf rear6-12Reference
Lawn/turf front16x6.50-8Reference
Lawn/turf rear23x8.50-12Reference
Length160 cmReference
Width84 cmReference
Height (steering wheel)101 cmReference
Ground clearance15 cmReference
Front axleCast-ironReference
Front tread68 cmReference
Rear tread68 cmReference
Cub Cadet 71 attachments
38" mid-mount mower deckReference
42" mid-mount mower deckReference
48" mid-mount mower deckReference
snowblowerReference
bladeReference
71 Serial Numbers
Location:Serial number plate on the rear of the tractor.Reference
1965127161Reference
1966137051Reference
1967180268Reference
Final218009Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemgeneratorReference
Charging amps15Reference
Battery volts12Reference
Attachment overview
38" mid-mount mower deckReference
42" mid-mount mower deckReference
48" mid-mount mower deckReference
SnowblowerReference
BladeReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
