Tractor · 1998Unverified

Cub Cadet 7205

Name: Cub Cadet 7205
Brand: Cub Cadet

Cub Cadet 7205 — Sub-Compact Utility tractor · 18 hp. Reference specifications; pending source verification.

The Cub Cadet 7205 is a compact tractor, rated at 18 horsepower, which falls within its designated class. Manufactured from 1998 to 2003, this model is equipped with a 3-cylinder diesel liquid-cooled engine, coupled with a hydrostatic transmission and four-wheel drive. The listed weight of the 7205 is 903 kilograms, making it suitable for tasks on land areas of approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

18 hp

Weight

903 kg

Catalogue coverage

Variants represented

Richest spec table

96 rows

Recorded power

18 hp

Recorded weight

903 kg

Transmissions

hydrostatic

Production years

1998-2003

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerCub CadetReference

Sub-Compact Utility tractorReference

Original price$13,050 (2000 )Reference

Original price$14,300 (2003 )Reference

Four-wheel driveReference

Differential lockmechanical rearReference

Power steeringReference

Mechanical dry shoe brakesReference

Two-post folding ROPS.Reference

Variants

70002WD gearReference

72004WD gearReference

72054WD hydroReference

Engine

Mitsubishi 1.1L 3-cyl dieselReference

Fuel tank20.1 LReference

Engine14.9 kWReference

MitsubishiReference

dieselReference

3-cylinderReference

liquid-cooled inlineReference

Displacement1.1 LReference

Bore/Stroke78 x 78 mmReference

Power14.9 kWReference

Fuel systemindirect injectionReference

Air cleanerdryReference

Rated RPM2500Reference

Idle RPM950-2680Reference

Firing order1-3-2Reference

Starter volts12Reference

Coolant capacity5.7 LReference

Intake valve clearance0.254 mmReference

Exhaust valve clearance0.254 mmReference

Oil capacity4.2 LReference

Oil change100 hReference

Transmission

hydrostaticReference

TypehydrostaticReference

Gearsinfinite forward and reverse (2-range)Reference

Oil capacity18.0 LReference

PTO & Hydraulics

PTO (claimed)13.0 kWReference

Typeopen centerReference

Pressure147.1 barReference

Pump flow22.0 lpmReference

Total flow34.8 lpmReference

Steering flow12.9 lpmReference

Rear TypeIReference

Controlposition controlReference

Rear lift (at ends)635 kgReference

Rear lift (at 24"/610mm)444 kgReference

Rear PTOliveReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@2356Reference

Mid PTOliveReference

Mid PTO Type2000 (1.0)Reference

Engine RPM2000@2470Reference

Dimensions

Wheelbase147 cmReference

Weight903 kgReference

Front tire6x12Reference

Rear tire9.5x16Reference

Weight430 kgReference

Ag front6x12Reference

Ag rear9.5x16Reference

Lawn/turf front23x8.5-12Reference

Lawn/turf rear33x12.5-15Reference

Industrial front23x8.5-12Reference

Industrial rear12-16.5Reference

Length270 cmReference

Width117 cmReference

Height (ROPS)200 cmReference

Ground clearance23 cmReference

903 kgReference

Max Drawbar379 kgReference

Cub Cadet 7205 attachments

60" mid-mount mower deckReference

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Battery volts12Reference

Attachment overview

60" mid-mount mower deckReference

Front-end loaderReference

BackhoeReference

60" Mower deck

Typemid-mount Cub Cadet 590-401-100Reference

Type3-bladeReference

Cutting width152 cmReference

Cub Cadet 590-457-100 Backhoe

Backhoe typeCub Cadet 590-457-100 BackhoeReference

Transport height169 cmReference

Bucket width20 cmReference

Bucket width30 cmReference

Bucket width40 cmReference

Bucket width45 cmReference

Bucket width60 cmReference

Digging depth198 cmReference

Reach from pivot238 cmReference

Loading height133 cmReference

Bucket Rotation180°Reference

Swing Arc180°Reference

Bucket force1179 kgReference

Dipperstick force562 kgReference

Capacities

Max capacity1450 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
