Tractor · 1998Unverified

Cub Cadet 7265

Name: Cub Cadet 7265
Brand: Cub Cadet

Cub Cadet 7265 — Compact Utility tractor · 26 hp. Reference specifications; pending source verification.

The Cub Cadet 7265 is a compact tractor model rated at 26 hp, featuring a 3-cylinder diesel liquid-cooled engine. It was manufactured from 1998 to 2003 and is equipped with a hydrostatic transmission and four-wheel drive. The model's listed weight is 1075 kg, making it suitable for tasks of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

26 hp

Weight

1075 kg

Catalogue coverage

Variants represented

Richest spec table

102 rows

Recorded power

26 hp

Recorded weight

1075 kg

Transmissions

hydrostatic

Production years

1998-2003

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerCub CadetReference

Compact Utility tractorReference

Original price$14,950 (2000 )Reference

Original price$16,500 (2003 )Reference

Four-wheel driveReference

Differential lockmechanical rearReference

Power steeringReference

Mechanical wet disc brakesReference

Two-post folding ROPS.Reference

Variants

7260gearReference

7265hydrostaticReference

Engine

Mitsubishi 1.3L 3-cyl dieselReference

Engine (gross)19.4 kWReference

MitsubishiReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.3 LReference

Bore/Stroke78 x 92 mmReference

Power (gross)19.4 kWReference

Fuel systemindirect injectionReference

Air cleanerdryReference

Pre-heatingglow plugsReference

Compression22:1Reference

Rated RPM2600Reference

Idle RPM950-2780Reference

Firing order1-3-2Reference

Starter volts12Reference

Starter power1.6 kWReference

Coolant capacity6.3 LReference

Intake valve clearance0.254 mmReference

Exhaust valve clearance0.254 mmReference

Oil capacity4.2 LReference

Oil change100 hReference

Transmission

hydrostaticReference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

Clutch215mm mechanical dry discReference

Oil capacity22.0 LReference

PTO & Hydraulics

PTO (claimed)17.2 kWReference

Typeopen centerReference

Pressure147.1 barReference

Valves1 or 2Reference

Pump flow29.5 lpmReference

Steering flow13.2 lpmReference

Rear TypeIReference

Controlposition control with optional draft controlReference

Rear lift (at 24"/610mm)749 kgReference

Rear PTOliveReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@2376Reference

Mid PTOliveReference

Mid PTO Type2000Reference

Engine RPM2000@2632Reference

Capacities

Fuel29.9 LReference

Front axle4.0 LReference

Max capacity2199 kgReference

Dimensions

Wheelbase165 cmReference

Weight1075 kgReference

Front tire7-14Reference

Rear tire9.5-24Reference

Weight453 kgReference

Standard tires (ag)Front: 7-14. Rear: 9.5-24Reference

Industrial front25x8.5-14Reference

Industrial rear13.6-16Reference

Length292 cmReference

Width131 cmReference

Height (ROPS)212 cmReference

Ground clearance30 cmReference

1075 kgReference

Max Drawbar379 kgReference

Max front axle969 kgReference

Max rear axle1349 kgReference

Cub Cadet 7265 attachments

60" mid-mount mower deckReference

72" mid-mount mower deckReference

front-end loaderReference

backhoeReference

7265 Serial Numbers

Location:Serial number plate on the right side of the tractor frame, just behind the front axle.Reference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps50Reference

Charging volts12Reference

Battery CCA500Reference

Battery volts12Reference

Attachment overview

60" mid-mount mower deckReference

72" mid-mount mower deckReference

Front-end loaderReference

BackhoeReference

Cub Cadet 590-408-100 Backhoe

Backhoe typeCub Cadet 590-408-100 BackhoeReference

Transport height182 cmReference

Bucket width20 cmReference

Bucket width30 cmReference

Bucket width40 cmReference

Bucket width45 cmReference

Bucket width60 cmReference

Digging depth228 cmReference

Reach from pivot284 cmReference

Loading height172 cmReference

Bucket Rotation180°Reference

Swing Arc180°Reference

Bucket force1224 kgReference

Dipperstick force816 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
