Tractor · 2004Unverified
Cub Cadet 7530
Cub Cadet 7530 — Compact Utility tractor · 26 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
26 hp
Weight
1075 kg
Hover a source tag to verify
Overview
DistributorCub CadetReference
ManufacturerMitsubishiReference
Compact Utility tractorReference
Original price was $12,800 in 2007Reference
Four-wheel driveReference
Power steeringReference
Mechanical wet disc brakesReference
Two-post folding ROPS.Reference
Engine
Mitsubishi 1.5L 3-cyl dieselReference
Engine22.4 kWReference
Mitsubishi K3MReference
turbocharged dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke84 x 90 mmReference
Power22.4 kWReference
Fuel systemBosch pump with DLLA 150 P injectorsReference
Pre-heatingglow plugsReference
Pre-heatingthermostartReference
Compression18:1Reference
Rated RPM2500Reference
Firing order1-3-2Reference
Starter volts12Reference
Coolant capacity5.5 LReference
Intake valve clearance0.254 mmReference
Exhaust valve clearance0.254 mmReference
Oil capacity5.0 LReference
Oil change100 hReference
Transmission
8-speed sync shuttleReference
Typesync shuttleReference
Gears8 forward and reverseReference
Clutch215mm dry discReference
Oil capacity30.0 LReference
Four gears (1-4) in two ranges (L-H) with left-hand shuttle. Clutch must be used to shift. Tractor must be stopped to change ranges.Reference
PTO & Hydraulics
PTO (claimed)19.4 kWReference
Hydraulic system29.9 LReference
Typeopen centerReference
Capacity29.9 LReference
Pump flow27.3 lpmReference
Total flow39.4 lpmReference
Steering flow12.5 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at ends)1200 kgReference
Rear lift (at 24"/610mm)780 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2376Reference
Mid PTOoptionalReference
Mid PTO Type2000Reference
Capacities
Fuel26.9 LReference
Dimensions
Wheelbase170 cmReference
Weight1075 kgReference
Front tire7-14Reference
Rear tire11.2-24Reference
Weight432 kgReference
Ag front7-14Reference
Ag rear11.2-24Reference
Lawn/turf front25 x 8.5-14Reference
Lawn/turf rear13.6-16Reference
Industrial front27 x 8.5-15Reference
Industrial rear15 x 19.5Reference
Length307 cmReference
Width135 cmReference
Height (ROPS)210 cmReference
Max Drawbar439 kgReference
Ground clearance38 cmReference
Cub Cadet 7530 attachments
front-end loaderReference
backhoeReference
7530 Serial Number Location
Serial number plate on the right side of the 7530 tractor frame, above the front axle.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps50Reference
Charging volts12Reference
Battery CCA500Reference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
Cub Cadet 633 Backhoe
Backhoe typeCub Cadet 633 BackhoeReference
Transport height182 cmReference
Bucket width20 cmReference
Bucket width30 cmReference
Bucket width40 cmReference
Bucket width45 cmReference
Bucket width60 cmReference
Digging depth228 cmReference
Reach from pivot284 cmReference
Loading height172 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force1224 kgReference
Dipperstick force816 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
