Tractor · 2004Unverified

Cub Cadet 8354

Name: Cub Cadet 8354
Brand: Cub Cadet

Cub Cadet 8354 — Compact Utility tractor · 28 hp. Reference specifications; pending source verification.

The Cub Cadet 8354 is a compact tractor model rated at 28 hp. It was manufactured from 2004 to 2007 and features a 3-cylinder diesel liquid-cooled engine. The tractor drives through four-wheel drive with an 8-speed gearbox, with a listed weight of 1756 kg. It is designed for use on areas of approximately up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

28 hp

Weight

1756 kg

Catalogue coverage

Variants represented

Richest spec table

74 rows

Recorded power

28 hp

Recorded weight

1756 kg

Transmissions

8-speed synchronized shuttle

Production years

2004-2007

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

DistributorCub CadetReference

ManufacturerDaedongReference

Compact Utility tractorReference

Original price was $15,600 in 2007Reference

Four-wheel driveReference

Differential lockmechanical rearReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS.Reference

Engine

Daedong 1.6L 3-cyl dieselReference

Fuel tank43.5 LReference

Engine26.1 kWReference

DaedongReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.6 LReference

Power26.1 kWReference

Fuel systemindirect injectionReference

Air cleanerdual element, cyclone typeReference

Rated RPM2700Reference

Starter volts12Reference

Transmission

8-speed synchronized shuttleReference

Typesynchronized shuttleReference

Gears8 forward and reverseReference

Clutchdry discReference

PTO & Hydraulics

PTO (claimed)21.1 kWReference

Typeopen centerReference

Pump flow29.9 lpmReference

Total flow47.3 lpmReference

Steering flow17.8 lpmReference

Rear TypeIReference

Controlposition and draft controlReference

Rear lift (at ends)1242 kgReference

Rear lift (at 24"/610mm)1027 kgReference

Rear PTOindependentReference

Rear PTO Type540Reference

Mid PTOindependentReference

Mid PTO Type2000Reference

Dimensions

Wheelbase166 cmReference

Weight1756 kgReference

Front tire7-16Reference

Rear tire12.4-24Reference

Weight428 kgReference

Ag front7-16Reference

Ag rear12.4-24Reference

Lawn/turf front27 x 8.5 x 15Reference

Lawn/turf rear41 x 14-20Reference

Industrial front27 x 10.5-15Reference

Industrial rear43 x 16-20Reference

Length320 cmReference

Width145 cmReference

Height (ROPS)234 cmReference

Cub Cadet 8354 attachments

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Battery volts12Reference

Attachment overview

Front-end loaderReference

BackhoeReference

Cub Cadet 644 Backhoe

Backhoe typeCub Cadet 644 BackhoeReference

Transport height190 cmReference

Bucket width22 cmReference

Bucket width30 cmReference

Bucket width40 cmReference

Bucket width45 cmReference

Bucket width60 cmReference

Bucket width91 cmReference

Digging depth228 cmReference

Reach from pivot302 cmReference

Loading height167 cmReference

Bucket Rotation170°Reference

Swing Arc180°Reference

Bucket force1213 kgReference

Dipperstick force954 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
