Tractor · 2008Unverified

Cub Cadet Ex2900

Name: Cub Cadet Ex2900
Brand: Cub Cadet

Cub Cadet Ex2900 — Ex Series · 23 hp. Reference specifications; pending source verification.

The Cub Cadet Ex2900 is a compact tractor model, rated at 23 hp, making it suitable for smaller-scale operations. It was manufactured from 2008 to 2011. The tractor features a 3-cylinder diesel liquid-cooled engine, which is connected to a hydrostatic transmission with four-wheel drive. The listed weight of the Ex2900 is 1156 kg, and it is designed for use on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

23 hp

Weight

1156 kg

Catalogue coverage

Variants represented

Richest spec table

64 rows

Recorded power

23 hp

Recorded weight

1156 kg

Transmissions

Hydrostatic

Production years

2008-2011

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

DistributorCub CadetReference

ManufacturerYanmarReference

Compact Utility tractorReference

Original price$16,289 (2009)Reference

Four-wheel driveReference

SteeringpowerReference

Wet disc brakesReference

Foldable ROPS standard. Optional steel cab.Reference

Engine

Yanmar 1.6L 3-cyl dieselReference

Fuel tank23.8 LReference

Engine21.4 kWReference

YanmarReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.6 LReference

Bore/Stroke88 x 90 mmReference

Power21.4 kWReference

Air cleanerdual dry elementsReference

Rated RPM2600Reference

Oil capacity4.0 LReference

Coolant capacity4.4 LReference

Transmission

HydrostaticReference

TypeHydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

Oil capacity20.4 LReference

PTO & Hydraulics

PTO (claimed)16.9 kWReference

Typeopen centerReference

Pump flow21.2 lpmReference

Total flow37.5 lpmReference

Steering flow16.3 lpmReference

Rear TypeIReference

Rear lift (at 24"/610mm)498 kgReference

Rear PTOliveReference

Rear PTO Type540Reference

Mid PTO Type2100Reference

Dimensions

Wheelbase154 cmReference

Weight1156 kgReference

Front tire7-14Reference

Rear tire11.2-24Reference

Ag front7-14Reference

Ag rear11.2-24Reference

Lawn/turf front25x8.5-14Reference

Lawn/turf rear13.6-16Reference

Industrial front25x8.5-14Reference

Industrial rear15-19.5Reference

Length278 cmReference

Width150 cmReference

Operating weight1156 kgReference

Ground clearance25 cmReference

Cub Cadet Ex2900 attachments

front-end loaderReference

backhoeReference

Ex2900 Serial Number Location

Serial number tag on the right side of the Cub Cadet Yanmar Ex2900, above the front axle.Reference

Electrical

GroundnegativeReference

Battery volts12Reference

Attachment overview

Front-end loaderReference

BackhoeReference

Cub Cadet CB75 Backhoe

Backhoe typeCub Cadet CB75 BackhoeReference

Digging depth226 cmReference

2-Foot flat digging depth220 cmReference

Reach from pivot314 cmReference

Loading height204 cmReference

Bucket force1182 kgReference

Dipperstick force826 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
