Tractor · 2008Unverified
Cub Cadet Sc2400
Cub Cadet Sc2400 — Sub-Compact Utility tractor · 24 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
24 hp
Weight
580 kg
Hover a source tag to verify
Overview
DistributorCub CadetReference
ManufacturerYanmarReference
Sub-Compact Utility tractorReference
Original price was $11,499 in 2009Reference
Four-wheel driveReference
Differential lockmechanical rearReference
SteeringpowerReference
Wet disc brakesReference
Two-post fixed ROPS standard. Optional steel cab.Reference
Variants
Sc2400 TDincludes 60-inch mid-mount mowerReference
Sc2400 TLincludes loaderReference
Sc3400 TLDincludes mower and loaderReference
Sc2450tractor backhoeReference
Engine
Yanmar 0.9L 3-cyl dieselReference
Fuel tank22.0 LReference
Engine (gross)17.9 kWReference
Engine (net)15.2 kWReference
Yanmar 3TNV72Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement0.9 LReference
Bore/Stroke72 x 74 mmReference
Power (net)15.2 kWReference
Power (gross)17.9 kWReference
Fuel systemindirect injectionReference
Air cleaner4-inch dry elementReference
Rated RPM3300Reference
Idle RPM1150-3470Reference
StarterelectricReference
Starter volts12Reference
Oil capacity2.4 LReference
Coolant capacity3.2 LReference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
Oil capacity7.6 LReference
PTO & Hydraulics
PTO (claimed)12.3 kWReference
Typeopen centerReference
Pump flow13.2 lpmReference
Total flow26.9 lpmReference
Steering flow13.6 lpmReference
Rear TypeI (limited)Reference
Rear lift (at 24"/610mm)299 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@3111Reference
Mid PTOindependentReference
Mid PTO Type2100 (SAE 16/32)Reference
Engine RPM2100@3338Reference
Dimensions
Wheelbase139 cmReference
Weight580 kgReference
Front tire18x8.5-10Reference
Rear tire26x12.0-12Reference
Weight166 kgReference
Ag front18x8.5-10Reference
Ag rear26x12.0-12Reference
Lawn/turf front18x8.50-10Reference
Lawn/turf rear26x12.00-12Reference
Length242 cmReference
Width113 cmReference
Height (steering wheel)126 cmReference
Height (ROPS)181 cmReference
Operating weight580 kgReference
Ground clearance19 cmReference
Cub Cadet Sc2400 attachments
60" mid-mount mower deckReference
snowblowerReference
bladeReference
front-end loaderReference
Sc2400 Serial Number Location
Serial number plate on the right side of the Sc2400 frame, above the front axle.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps40Reference
Battery volts12Reference
Attachment overview
60" mid-mount mower deckReference
SnowblowerReference
BladeReference
Front-end loaderReference
60" Mower deck
Typemid-mount Cub Cadet MM60RSeReference
Type3-bladeReference
Cutting width152 cmReference
Cut height2 to 10 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
