The Cub Cadet XT1 LT46 EFI is a lawn tractor model with a rated output of 15 hp, placing it in the middle of its class in terms of power. It was manufactured in 2016. The XT1 LT46 EFI is powered by a 1-cylinder petrol air-cooled engine, which drives two-wheel drive via a hydrostatic transmission. Its listed weight is 195 kg, making it suitable for tasks covering up to 200 ac.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
15 hp
Weight
195 kg
Catalogue coverage
Variants represented
2
Richest spec table
38 rows
Recorded power
15 hp
Transmissions
hydrostatic
Production years
2016-2016
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerCub Cadet (a part of MTD)Reference
Lawn tractorReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
15.4HP Zongshen 547cc 1-cyl gasolineReference
Fuel tank9.5 LReference
Zongshen 9X90HUReference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement33.4 ciReference
Power11.5 kWReference
Fuel systemelectronic fuel injectionReference
StarterelectricReference
Starter volts12Reference
Oil capacity1.7 LReference
Transmission
hydrostaticReference
TransmissionTuff Torq K46Reference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
Dimensions
Weight195 kgReference
Front tire15x6-6Reference
Rear tire20x8-8Reference
Lawn/turf front15x6-6Reference
Lawn/turf rear20x8-8Reference
Length172 cmReference
Height (steering wheel)107 cmReference
Cub Cadet XT1 LT46 EFI attachments
46" mid-mount mower deckReference
Electrical
GroundnegativeReference
Battery CCA230Reference
Battery volts12Reference
46" Mower deck
Typemid-mount Cub CadetReference
Type2-blade with manual liftReference
Cutting width116 cmReference
Overall width134 cmReference
Cut height2 to 10 cmReference
Cut positions12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
