Tractor · 1952Unverified

Custom 98

Name: Custom 98
Brand: Custom

Custom 98 — Row-Crop tractor · 62 hp. Reference specifications; pending source verification.

The Custom 98 is a tractor with an approximate power output of 62 hp, categorising it as a lighter model within its class. It was produced from 1952 to 1954. It features a 6-cylinder petrol liquid-cooled engine, paired with two-wheel drive and a 5-speed gearbox. Its operating weight is listed as 4436 to 4696 pounds, and it is suited to working on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

62 hp

Weight

4436 to 4696 pounds

Catalogue coverage

Variants represented

Richest spec table

51 rows

Recorded power

62 hp

Recorded weight

2012 kg

Transmissions

5-speed gear

Production years

1952-1954

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerCustomReference

Row-Crop tractorReference

Built in Hustisford, Wisconsin, USAReference

Two-wheel driveReference

Manual steeringReference

Open operator station.Reference

Variants

98Rtricycle frontReference

98Wwide frontReference

Engine

Chrysler 4.1L 6-cyl gasolineReference

Engine46.2 kWReference

Plows3-4 (14-inch)Reference

Chrysler 8AReference

gasolineReference

6-cylinderReference

liquid-cooledReference

Displacement4.1 LReference

Bore/Stroke87 x 114 mmReference

Power46.2 kWReference

Compression6.6:1Reference

Rated RPM1800Reference

Torque226.5 NmReference

Torque RPM1200Reference

Firing order1-5-3-6-2-4Reference

Transmission

5-speed gearReference

TypegearReference

Gears5 forward and 1 reverseReference

PTO & Hydraulics

Rear PTO Type540 (1.375)Reference

Dimensions

98W Wheelbase237 cmReference

98R Wheelbase238 cmReference

Weight4436 to 4696 poundsReference

Front tire6-16Reference

98W Rear tire14-30Reference

98W Standard tires (ag)Front: 6-16. Rear: 14-30Reference

98R Standard tires (ag)Front: 6-16. Rear: 12-38Reference

98W Length348 cmReference

98R Length353 cmReference

98W Height198 cmReference

98R Height203 cmReference

98W Shipping weight2012 kgReference

98W Shipping weight2130 kgReference

98W Ground clearance43 cmReference

98R Ground clearance63 cmReference

98R Front tread20 to 35 cmReference

98W Front tread140 to 156 cmReference

98R Rear tread142 to 213 cmReference

98W Rear tread168 to 199 cmReference

Capacities

Diameter27 cmReference

Width19 cmReference

RPM1011Reference

Speed887.27 meters/minReference

Speeds

With 14-30 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
