Tractor · 1948Unverified
Custom E
Custom E — Row-Crop tractor · 62 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
62 hp
Weight
4436 to 4696 pounds
Hover a source tag to verify
Overview
ManufacturerCustomReference
Row-Crop tractorReference
Built in Shelbyville, Indiana, USAReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Variants
ERtricycle frontReference
EWwide frontReference
Engine
Chrysler 4.1L 6-cyl gasolineReference
Engine46.2 kWReference
Chrysler 8AReference
gasolineReference
6-cylinderReference
liquid-cooledReference
Displacement4.1 LReference
Bore/Stroke87 x 114 mmReference
Power46.2 kWReference
Compression6.6:1Reference
Rated RPM1800Reference
Torque226.5 NmReference
Torque RPM1200Reference
Transmission
5-speed gearReference
TypegearReference
Gears5 forward and 1 reverseReference
Dimensions
EW Wheelbase237 cmReference
ER Wheelbase238 cmReference
Weight4436 to 4696 poundsReference
Front tire6-16Reference
ER Rear tire12-38Reference
ER Standard tires (ag)Front: 6-16. Rear: 12-38Reference
EW Standard tires (ag)Front: 6-16. Rear: 13-30Reference
EW Length348 cmReference
ER Length353 cmReference
EW Height198 cmReference
ER Height203 cmReference
EW Weight2130 kgReference
ER Weight2012 kgReference
EW Ground clearance43 cmReference
ER Ground clearance63 cmReference
EW Front tread140 to 156 cmReference
EW Rear tread168 to 199 cmReference
ER Rear tread142 to 213 cmReference
Capacities
Diameter27 cmReference
Width19 cmReference
RPM1011Reference
Speed887.27 meters/minReference
Speeds
With 11-38 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
