Tractor · 1948Unverified
Custom H
Custom H — Row-Crop tractor · 56 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
56 hp
Weight
4136 to 4296 pounds
Hover a source tag to verify
Overview
ManufacturerCustomReference
Row-Crop tractorReference
Built in Shelbyville, Indiana, USAReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Variants
HRtricycle frontReference
HWwide frontReference
Engine
Chrysler 3.8L 6-cyl gasolineReference
Engine41.8 kWReference
Chrysler 6AReference
gasolineReference
6-cylinderReference
liquid-cooledReference
Displacement3.8 LReference
Bore/Stroke83 x 117 mmReference
Power41.8 kWReference
Compression6.7:1Reference
Rated RPM1800Reference
Torque206.1 NmReference
Torque RPM1200Reference
Transmission
5-speed gearReference
TypegearReference
Gears5 forward and 1 reverseReference
Dimensions
HW Wheelbase232 cmReference
HR Wheelbase232 cmReference
Weight4136 to 4296 poundsReference
Front tire6-16Reference
HW Rear tire12-30Reference
HW Standard tires (ag)Front: 6-16. Rear: 12-30Reference
HR Standard tires (ag)Front: 6-16. Rear: 11-38Reference
HW Length342 cmReference
HR Length347 cmReference
HW Height198 cmReference
HR Height203 cmReference
HW Weight1948 kgReference
HR Weight1876 kgReference
HW Front tread140 to 156 cmReference
HW Rear tread168 to 199 cmReference
HR Rear tread142 to 213 cmReference
Capacities
Diameter27 cmReference
Width19 cmReference
RPM1011Reference
Speed887.27 meters/minReference
Speeds
With 11-38 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
