The Daedong CK20 is a tractor rated at 17 hp — making it one of the more compact options in its class. Under the hood is a 3-cylinder diesel liquid-cooled engine, driving through four-wheel drive with a hydrostatic transmission. Listed weight is 889 kg, and it is aimed at jobs of around up to 200 ac. The available specification table below shows both UK and US units.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
17 hp
Weight
889 kg
Catalogue coverage
Variants represented
2
Richest spec table
44 rows
Recorded power
17 hp
Recorded weight
889 kg
Transmissions
6-speed
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerDaedongReference
Built in KoreaReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
ROPs; foldable ROPs optionalReference
Variants
CK20HSThydrostaticReference
Engine
Daedong 0.9L 3-cyl dieselReference
Fuel tank20.0 LReference
Engine15.7 kWReference
Daedong 3C093Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement0.9 LReference
Bore/Stroke75 x 70 mmReference
Power15.7 kWReference
Rated RPM2800Reference
Transmission
6-speedReference
Gears6 forward and 2 reverseReference
TransmissionhydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
PTO (claimed)12.3 kWReference
Valves1Reference
Total flow29.0 lpmReference
Rear TypeIReference
Rear lift (at 24"/610mm)503 kgReference
Rear PTOtransmissionReference
Rear PTO Type540Reference
Mid PTO Type2000Reference
Front PTO Type2800Reference
Dimensions
Wheelbase147 cmReference
Weight889 kgReference
Front tire6-12Reference
Rear tire9.5-16Reference
Ag front6-12Reference
Ag rear9.5-16Reference
Lawn/turf front23x8.50-12Reference
Lawn/turf rear33x12.5-16.5Reference
Industrial front23x8.50x12Reference
Industrial rear12-16.5Reference
Length268 cmReference
Width112 cmReference
Height196 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
