Tractor · Unverified
Daedong CK20
Daedong CK20 · 17 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
17 hp
Weight
889 kg
Hover a source tag to verify
Overview
ManufacturerDaedongReference
Built in KoreaReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
ROPs; foldable ROPs optionalReference
Variants
CK20HSThydrostaticReference
Engine
Daedong 0.9L 3-cyl dieselReference
Fuel tank20.0 LReference
Engine15.7 kWReference
Daedong 3C093Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement0.9 LReference
Bore/Stroke75 x 70 mmReference
Power15.7 kWReference
Rated RPM2800Reference
Transmission
6-speedReference
Gears6 forward and 2 reverseReference
TransmissionhydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
PTO (claimed)12.3 kWReference
Valves1Reference
Total flow29.0 lpmReference
Rear TypeIReference
Rear lift (at 24"/610mm)503 kgReference
Rear PTOtransmissionReference
Rear PTO Type540Reference
Mid PTO Type2000Reference
Front PTO Type2800Reference
Dimensions
Wheelbase147 cmReference
Weight889 kgReference
Front tire6-12Reference
Rear tire9.5-16Reference
Ag front6-12Reference
Ag rear9.5-16Reference
Lawn/turf front23x8.50-12Reference
Lawn/turf rear33x12.5-16.5Reference
Industrial front23x8.50x12Reference
Industrial rear12-16.5Reference
Length268 cmReference
Width112 cmReference
Height196 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
