The Daedong CK30 is a tractor rated at 24 hp — making it one of the more compact options in its class. Under the hood is a 3-cylinder diesel liquid-cooled engine, driving through four-wheel drive with a hydrostatic transmission. Listed weight is 1379 kg, and it is aimed at jobs of around up to 200 ac. Available dimensions and performance figures follow in both unit systems.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
24 hp
Weight
1379 kg
Catalogue coverage
Variants represented
2
Richest spec table
42 rows
Recorded power
24 hp
Recorded weight
1379 kg
Transmissions
8-speed
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerDaedongReference
Built in KoreaReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
foldable ROPsReference
Engine
Daedong 1.5L 3-cyl dieselReference
Fuel tank29.9 LReference
Engine22.4 kWReference
Daedong 3A1150DReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Power22.4 kWReference
Rated RPM2600Reference
Transmission
8-speedReference
Gears8 forward and reverseReference
PTO & Hydraulics
PTO (claimed)17.9 kWReference
Valves1 or 2Reference
Total flow48.1 lpmReference
Rear TypeIReference
Rear lift (at 24"/610mm)800 kgReference
Rear PTOliveReference
Rear PTO Type540, 1000Reference
Mid PTOoptionalReference
Mid PTO Type2000Reference
Front PTO Type2600Reference
Dimensions
Wheelbase167 cmReference
Weight1379 kgReference
Front tire7-14Reference
Rear tire11.2-24Reference
Ag front7-14Reference
Ag rear11.2-24Reference
Lawn/turf front27x8.50-15Reference
Lawn/turf rear41x14.00-20Reference
Industrial front25x8.50-14Reference
Industrial rear15-19.5Reference
Length310 cmReference
Width138 cmReference
Height245 cmReference
Ground clearance35 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
