Tractor · Unverified
Daedong EX35
Daedong EX35 · 29 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
29 hp
Weight
1663 kg
Hover a source tag to verify
Overview
ManufacturerDaedongReference
Built in KoreaReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Engine
Daedong 1.8L 3-cyl dieselReference
Fuel tank37.4 LReference
Engine28.3 kWReference
Daedong 3B183LXMReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.8 LReference
Power28.3 kWReference
Rated RPM2600Reference
Transmission
12-speedReference
Gears12 forward and reverseReference
TransmissionhydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
PTO (claimed)21.5 kWReference
Total flow57.5 lpmReference
Rear PTOindependentReference
Rear PTO Type540Reference
Mid PTO Type2000Reference
Dimensions
Wheelbase176 cmReference
Weight1663 kgReference
Front tire7-16Reference
Rear tire12.4-24Reference
Ag front7-16Reference
Ag rear12.4-24Reference
Length341 cmReference
Width154 cmReference
Height238 cmReference
Ground clearance32 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
