Tractor · Unverified
Daedong EX50
Daedong EX50 · 40 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
40 hp
Weight
1784 kg
Hover a source tag to verify
Overview
ManufacturerDaedongReference
Built in KoreaReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Engine
Daedong 2.4L 3-cyl dieselReference
Fuel tank37.4 LReference
Engine37.3 kWReference
Daedong 4B243LXMReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.4 LReference
Power37.3 kWReference
Rated RPM2600Reference
Transmission
12-speedReference
Gears12 forward and reverseReference
TransmissionhydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
PTO (claimed)29.5 kWReference
Total flow63.6 lpmReference
Rear PTOindependentReference
Rear PTO Type540Reference
Mid PTO Type2000Reference
Dimensions
Wheelbase187 cmReference
Weight1784 kgReference
Front tire9.5-16Reference
Rear tire13.6-26Reference
Ag front9.5-16Reference
Ag rear13.6-26Reference
Length345 cmReference
Width163 cmReference
Height244 cmReference
Ground clearance37 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
