The Daedong LK3054 is a tractor with a rated power of 29 hp, which places it at the lighter end of its class. Under the hood is a 3-cylinder diesel liquid-cooled engine, paired with four-wheel drive with a hydrostatic transmission. It has a listed operating weight of 1138 kg, and it suits operations of up to 200 ac. Recorded specifications in UK and US units are listed below.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
29 hp
Weight
1138 kg
Catalogue coverage
Variants represented
2
Richest spec table
35 rows
Recorded power
29 hp
Recorded weight
1138 kg
Transmissions
8-speed
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerDaedongReference
Built in KoreaReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Engine
Daedong 1.4L 3-cyl dieselReference
Fuel tank28.0 LReference
Engine21.3 kWReference
Daedong TD1400B-1Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.4 LReference
Bore/Stroke85 x 82 mmReference
Power21.3 kWReference
Air cleanerdual dry elementReference
Compression21:1Reference
Rated RPM2800Reference
Transmission
8-speedReference
Gears8 forward and reverseReference
PTO & Hydraulics
Valves1Reference
Total flow32.6 lpmReference
Rear TypeIReference
Rear lift975 kgReference
Rear PTOtransmissionReference
Rear PTO Type538/991Reference
Dimensions
Weight1138 kgReference
Front tire7-14Reference
Rear tire11.2-24Reference
Ag front7-14Reference
Ag rear11.2-24Reference
Length282 cmReference
Width136 cmReference
Height197 cmReference
Ground clearance28 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
