Tractor · Unverified
Daedong LK4504
Daedong LK4504 · 46 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
46 hp
Weight
1630 kg
Hover a source tag to verify
Overview
ManufacturerDaedongReference
Built in KoreaReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Engine
Daedong 2.2L 4-cyl dieselReference
Engine34.3 kWReference
Daedong 4A220AReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Bore/Stroke87 x 92 mmReference
Power34.3 kWReference
Air cleanerdual dry elementReference
Compression22:1Reference
Rated RPM2800Reference
Transmission
8-speedReference
Gears8 forward and reverseReference
PTO & Hydraulics
Valves1Reference
Total flow44.7 lpmReference
Rear TypeIReference
Rear lift1143 kgReference
Rear PTOtransmissionReference
Rear PTO Type578/725/1000/1194Reference
Dimensions
Weight1630 kgReference
Front tire9.5-16Reference
Rear tire13.6-26Reference
Ag front9.5-16Reference
Ag rear13.6-26Reference
Length330 cmReference
Width148 cmReference
Height226 cmReference
Ground clearance37 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
