Tractor · 1956Unverified
David Brown 2D
David Brown 2D — Tool Carrier tractor · 14 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
14 hp
Weight
861 kg
Hover a source tag to verify
Overview
ManufacturerDavid BrownReference
Tool Carrier tractorReference
Built in Meltham Mills, Huddersfield, EnglandReference
Two-wheel driveReference
SteeringmanualReference
Mechanical internal expanding brakesReference
Open operator station.Reference
Engine
David Brown 1.3L 2-cyl dieselReference
Engine10.5 kWReference
David BrownReference
dieselReference
2-cylinderReference
air-cooledReference
Displacement1.3 LReference
Bore/Stroke89 x 102 mmReference
Power10.5 kWReference
Fuel systemdirect injectionReference
Air cleaneroil bathReference
Rated RPM1800Reference
Operating RPM600-1800Reference
StarterelectricReference
Starter volts12Reference
Transmission
4-speed gearReference
TransmissionDavid BrownReference
TypegearReference
Gears4 forward and 1 reverseReference
Clutchdry discReference
PTO & Hydraulics
Typepneumatic mid liftReference
Rear PTOlive (optional)Reference
Rear PTO Type540Reference
Mid PTO Type560Reference
Dimensions
Wheelbase182 cmReference
Weight861 kgReference
Front tire4.00x15Reference
Rear tire6.00x22Reference
Ag front4.00x15Reference
Ag rear6.00x22Reference
Ag rear8.00x24Reference
Length295 cmReference
Width170 cmReference
Height139 cmReference
Front tread101 to 172 cmReference
Rear tread101 to 172 cmReference
Speeds
With 6.00x22 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
