Tractor · 1953Unverified
David Brown 50D
David Brown 50D · 50 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
50 hp
Weight
2780 kg
Hover a source tag to verify
Overview
ManufacturerDavid BrownReference
Two-wheel driveReference
SteeringmanualReference
Mechanical drum brakesReference
Open operator station.Reference
Engine
David Brown 4.1L 6-cyl dieselReference
Fuel tank54.9 LReference
Engine37.3 kWReference
David BrownReference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement4.1 LReference
Bore/Stroke92 x 102 mmReference
Power37.3 kWReference
Compression16:1Reference
Rated RPM1800Reference
Idle RPM700-1800Reference
Oil capacity10.4 LReference
Coolant capacity18.9 LReference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 2 reverseReference
Clutch10-inch dry discReference
Oil capacity22.7 LReference
PTO & Hydraulics
Rear PTO Type540Reference
Dimensions
Wheelbase207 cmReference
Weight2780 kgReference
Front tire7.50-18Reference
Rear tire14-30Reference
Ag front7.50-18Reference
Ag rear14-30Reference
Length342 cmReference
Width187 cmReference
Height (hood)165 cmReference
Ground clearance33 cmReference
50D Serial Numbers
1953VAD/6 10001Reference
1954VAD/6 ?????Reference
1955VAD/6 10400Reference
1956VAD/6 ?????Reference
1957VAD/6 ?????Reference
1958VAD/6 ?????Reference
FinalVAD/6 11260Reference
FAQ: How to read a serial number table.Reference
Speeds
With 14x30 rear tres,Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
