Backhoe Loader · 1965Unverified

David Brown 800

Name: David Brown 800
Brand: David Brown

David Brown 800 — Backhoe loader tractor · 45 hp. Reference specifications; pending source verification.

The David Brown 800 is a backhoe loader with a rated output of 45 hp — making it one of the more compact options in its class. It was produced from 1965 to 1970. Power comes from a 3-cylinder diesel liquid-cooled engine, driving through two-wheel drive with a 6-speed gearbox. Listed weight is 4177 kg, and it is aimed at jobs of around up to 200 ac. Full UK and US specifications are listed below, each with its source.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

45 hp

Weight

4177 kg

Catalogue coverage

Variants represented

Richest spec table

72 rows

Recorded power

45 hp

Recorded weight

4177 kg

Transmissions

6-speed mechanical shuttle

Production years

1965-1970

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerDavid BrownReference

Backhoe loader tractorReference

Two-wheel driveReference

Final drivesspur gearReference

Differential lockmechanical rearReference

Power steeringReference

Open operator station.Reference

Engine

David Brown 2.7L 3-cyl dieselReference

Engine33.6 kWReference

David BrownReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement2.7 LReference

Bore/Stroke100 x 114 mmReference

Power33.6 kWReference

Air cleaneroil bathReference

Rated RPM2200Reference

Torque162.7 NmReference

Torque RPM1400Reference

StarterelectricReference

Starter volts12Reference

Oil capacity7.7 LReference

Coolant capacity12.5 LReference

Transmission

6-speed mechanical shuttleReference

Typemechanical shuttleReference

Gears6 forward and reverseReference

Capacities

Fuel62.5 LReference

PTO & Hydraulics

Hydraulic system40.9 LReference

Typeopen centerReference

Capacity40.9 LReference

Pressure144.8 barReference

Pump flow104.5 lpmReference

Dimensions

Wheelbase199 cmReference

Weight4177 kgReference

Front tire7.50-16Reference

Rear tire16.9/14-24Reference

Weight1190 kgReference

Weight1270 kgReference

Industrial front7.50-16Reference

Industrial rear16.9/14-24Reference

Length721 cmReference

Width195 cmReference

Height (hood)130 cmReference

Max front axle4082 kgReference

Ground clearance29 cmReference

Front tread147 cmReference

Rear tread157 cmReference

Backhoe & Loader

Dig depth365 cmReference

Electrical

Charging systemgeneratorReference

Charging amps11Reference

Attachment overview

Front-end loaderReference

BackhoeReference

Wain-Roy 12' Backhoe

Backhoe typeWain-Roy 12' BackhoeReference

Bucket width35 cmReference

Bucket width45 cmReference

Bucket width60 cmReference

Digging depth365 cmReference

Reach from pivot474 cmReference

Loading height264 cmReference

Bucket Rotation180°Reference

Swing Arc185°Reference

Wain-Roy 14' Backhoe

Backhoe typeWain-Roy 14' BackhoeReference

Bucket width35 cmReference

Bucket width45 cmReference

Bucket width60 cmReference

Digging depth426 cmReference

Reach from pivot533 cmReference

Loading height314 cmReference

Bucket Rotation180°Reference

Swing Arc185°Reference

Speeds

With 16.9/14-24 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
