Backhoe Loader · 1965Unverified
David Brown 900
David Brown 900 — Backhoe loader tractor · 55 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
55 hp
Weight
4377 kg
Hover a source tag to verify
Overview
ManufacturerDavid BrownReference
Backhoe loader tractorReference
Two-wheel driveReference
Power steeringReference
Open operator station.Reference
Engine
David Brown 3.2L 4-cyl dieselReference
Engine41.0 kWReference
David BrownReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.2 LReference
Bore/Stroke100 x 102 mmReference
Power41.0 kWReference
Rated RPM2200Reference
Torque189.8 NmReference
Torque RPM1200Reference
StarterelectricReference
Starter volts12Reference
Transmission
6-speed mechanical shuttleReference
Typemechanical shuttleReference
Gears6 forward and reverseReference
Dimensions
Wheelbase196 cmReference
Weight4377 kgReference
Front tire7.50-16Reference
Rear tire16.9-30Reference
Weight1451 kgReference
Weight1474 kgReference
Industrial front7.50-16Reference
Industrial rear16.9-30Reference
Length746 cmReference
Width195 cmReference
Height (hood)157 cmReference
Max front axle4082 kgReference
Front tread147 cmReference
Rear tread152 cmReference
Backhoe & Loader
Dig depth426 cmReference
Attachment overview
Front-end loaderReference
BackhoeReference
Wain-Roy 14' Backhoe
Backhoe typeWain-Roy 14' BackhoeReference
Bucket width35 cmReference
Bucket width45 cmReference
Bucket width60 cmReference
Digging depth426 cmReference
Reach from pivot533 cmReference
Loading height314 cmReference
Bucket Rotation180°Reference
Swing Arc185°Reference
Wain-Roy 15' Backhoe
Backhoe typeWain-Roy 15' BackhoeReference
Bucket width35 cmReference
Bucket width45 cmReference
Bucket width60 cmReference
Digging depth457 cmReference
Reach from pivot568 cmReference
Loading height342 cmReference
Bucket Rotation180°Reference
Swing Arc185°Reference
Speeds
With 16.9x30 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
