Lawn Tractor · 1991Unverified
Deutz-Allis 512H
Deutz-Allis 512H — Lawn tractor · 13 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
13 hp
Hover a source tag to verify
Overview
DistributorDeutz-AllisReference
ManufacturerSimplicityReference
Lawn tractorReference
Built in Port Washington, Wisconsin, USAReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Variants
512Ggear driveReference
512HhydrostaticReference
Engine
12.5HP Briggs & Stratton 465cc 1-cyl gasolineReference
Fuel tank8.3 LReference
Briggs & StrattonReference
gasolineReference
1-cylinderReference
air-cooledReference
Displacement28.4 ciReference
Bore/Stroke87 x 78 mmReference
Power9.3 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchmanualReference
Dimensions
Wheelbase115 cmReference
Front tire15x6.00-6Reference
Rear tire18x8.50-8Reference
Lawn/turf front15x6.00-6Reference
Lawn/turf rear18x8.50-8Reference
Length165 cmReference
Width85 cmReference
Height (steering wheel)99 cmReference
Clearance (front axle)22 cmReference
Clearance (rear axle)15 cmReference
Deutz-Allis 512H attachments
36" mid-mount mower deckReference
512H Serial Number Location
Serial number plate on the left side of the 512H tractor frame, just behind the front axle.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
36" Mower deck
Typemid-mount Deutz-AllisReference
Cutting width91 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
