Tractor · 1985Unverified
Deutz-Allis 6060
Deutz-Allis 6060 — Row-Crop tractor · 64 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
64 hp
Max power
37.9 kW
Weight
6100 to 6465 pounds
Hover a source tag to verify
Overview
ManufacturerDeutz-AllisReference
Row-Crop tractorReference
Built in West Allis, Wisconsin, USAReference
Total built4,027Reference
Original price$21,460Reference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD (optional)Reference
Steeringhydrostatic powerReference
Differential hydraulic wet disc brakesReference
Four-post ROPS canopy. Cab and air-conditioning optional.Reference
Engine
Allis Chalmers 3.3L 4-cyl dieselReference
Drawbar (tested)37.9 kWReference
Allis Chalmers 433TReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.3 LReference
Bore/Stroke98 x 108 mmReference
Air cleanerpaper element with pre-cleanderReference
Compression14.1:1Reference
Rated RPM2300Reference
Starter volts12Reference
Oil capacity9.5 LReference
Coolant capacity16.1 LReference
Power at rated engine speed47.6 kWReference
Max power37.9 kWReference
Transmission
8-speed partially synchronizedReference
Typepartially synchronizedReference
Gears8 forward and 2 reverseReference
Oil capacity11.4 LReference
Two ranges with four gears in each range. Synchronized shifting between top two gears (3-4 and 7-8) in each range.Reference
PTO & Hydraulics
PTO (tested)47.6 kWReference
Typeopen centerReference
Valves2Reference
Pump flow43.1 lpmReference
Total flow71.9 lpmReference
Rear TypeIIReference
Rear lift (at 24"/610mm)1587 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Power at rated PTO speed48.4 kWReference
Capacities
Fuel121.1 LReference
Rear diff.35.0 LReference
Dimensions
Wheelbase236 cmReference
Wheelbase233 cmReference
Weight6100 to 6465 poundsReference
Front tire7.50-16Reference
Rear tire16.9-28Reference
Ag front7.50-16 (2WD)Reference
Ag front11.2-24 (4WD)Reference
Ag rear16.9-28 (2WD)Reference
Ag rear18.4-28 (4WD)Reference
Length372 cmReference
Width173 cmReference
Ground clearance45 cmReference
Ground clearance51 cmReference
Ground clearance67 cmReference
Shipping2766 kgReference
Operating2932 kgReference
Ballasted4057 kgReference
6060 Serial Numbers
Location:Right side of engine adapter flangeReference
19801001Reference
19811297Reference
19822463Reference
19833894Reference
19844572Reference
Final5027Reference
FAQ: How to read a serial number table.Reference
Electrical
Charging systemalternatorReference
Charging amps72Reference
Batteries1Reference
Batteries2 (optional)Reference
Battery volts12Reference
Deutz-Allis 6060 Height
Hood176 cmReference
ROPS273 cmReference
Cab262 cmReference
Exhaust279 cmReference
Test results
Diesel 8-speed 2WDJune 9 - 22, 1981Link: Nebraska Tractor Test 1397 fileReference
PTO performanceReference
Fuel use15.1 l/hourReference
Drawbar performanceReference
Fuel use14.4 l/hourReference
Gear 1-H used for power test.Reference
Max pull3105 kgReference
Gear 2-L used for pull test.Reference
Speeds
With 15.5-38 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
