Tractor · 1986Unverified

Deutz-Allis 6240

Name: Deutz-Allis 6240
Brand: Deutz-Allis

Deutz-Allis 6240 — Utility tractor · 43 hp. Reference specifications; pending source verification.

The Deutz-Allis 6240 is a compact tractor model rated at 43 hp. It was manufactured from 1986 to 1990 and is equipped with a 3-cylinder diesel air-cooled engine, driving through a four-wheel drive system with a powershift transmission. The listed weight of the 6240 ranges from 5776 to 6173 pounds. It is designed for use in areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

43 hp

Weight

5776 to 6173 pounds

Catalogue coverage

Variants represented

Richest spec table

66 rows

Recorded power

43 hp

Recorded weight

2619 kg

Transmissions

8-speed partially synchronized

Production years

1986-1990

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerDeutz-AllisReference

Utility tractorReference

Built in GermanyReference

Original price$18,100Reference

Two- or four-wheel driveReference

Differential lockmechanical rearReference

Power steeringReference

Mechanical drum brakesReference

Four-post ROPSReference

Variants

DX 3.10similar Deutz-Fahr modelReference

Engine

Deutz 2.8L 3-cyl dieselReference

Engine34.3 kWReference

Deutz F3L 912Reference

dieselReference

3-cylinderReference

air-cooledReference

Displacement2.8 LReference

Bore/Stroke100 x 120 mmReference

Power34.3 kWReference

Rated RPM2150Reference

Starter volts12Reference

Oil capacity8.0 LReference

Transmission

8-speed partially synchronizedReference

16-speed two-speed power shiftReference

Typepartially synchronizedReference

Gears8 forward and 4 reverseReference

Clutchdry discReference

Four synchronized gears (1-4) in two ranges, plus reverse range.Reference

TransmissionDual-SplitReference

Typetwo-speed power shiftReference

Gears16 forward and 8 reverseReference

PTO & Hydraulics

PTO (claimed)32.1 kWReference

Hydraulic system15.1 LReference

Hydraulic system28.4 LReference

Typeopen centerReference

Capacity15.1 LReference

Capacity28.4 LReference

Pressure175.0 barReference

Valves1 to 3Reference

Pump flow37.1 lpmReference

Rear TypeIReference

Rear lift (at ends)1900 kgReference

Front HitchIIReference

Front lift1000 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Front PTOindependentReference

Front PTO Type1000Reference

Capacities

Fuel75.7 LReference

Dimensions

2WD Wheelbase200 cmReference

4WD Wheelbase208 cmReference

Weight5776 to 6173 poundsReference

Front tire7.50-16Reference

2WD Rear tire14.9-28Reference

2WD Standard tires (ag)Front: 7.50-16. Rear: 14.9-28Reference

4WD Standard tires (ag)Front: 10.5-20. Rear: 14.9-28Reference

2WD Optional tires (ag)Front: 7.50-16. Rear: 14.9-24Reference

Width209 cmReference

Height (ROPS)224 cmReference

2WD Weight2619 kgReference

4WD Weight2800 kgReference

Rear tread149 to 190 cmReference

Deutz-Allis 6240 attachments

front-end loaderReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
