Tractor · 1986Unverified
Deutz-Allis 6275
Deutz-Allis 6275 — Utility tractor · 71 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
71 hp
Weight
6922 to 8333 pounds
Hover a source tag to verify
Overview
ManufacturerDeutz-AllisReference
Utility tractorReference
Built in GermanyReference
Two- or four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Hydraulic drum brakesReference
Four-post ROPS. StarCab optional.Reference
Variants
6275utilityReference
6275FnarrowReference
6275Llow-profileReference
DX 3.90similar Deutz-Fahr modelReference
Engine
Deutz 4.1L 4-cyl dieselReference
Engine55.9 kWReference
Deutz F4L 913Reference
dieselReference
4-cylinderReference
air-cooledReference
Displacement4.1 LReference
Bore/Stroke100 x 123 mmReference
Power55.9 kWReference
Rated RPM2350Reference
Starter volts12Reference
Oil capacity9.9 LReference
Transmission
12-speed partially synchronizedReference
TransmissionTriple-rangeReference
Typepartially synchronizedReference
Gears12 forward and 4 reverseReference
Clutchdry discReference
Four synchronized gears in three ranges, plus reverse range.Reference
PTO & Hydraulics
PTO (claimed)52.9 kWReference
Hydraulic system15.1 LReference
Typeopen centerReference
Capacity15.1 LReference
Pressure162.6 barReference
Valves1 to 3Reference
Pump flow43.1 lpmReference
Total flow67.0 lpmReference
Rear TypeIIReference
Rear lift3299 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Capacities
ROPS Fuel90.8 LReference
Cab Fuel106.0 LReference
Dimensions
2WD Wheelbase232 cmReference
4WD Wheelbase238 cmReference
Weight6922 to 8333 poundsReference
Front tire10.00-16Reference
2WD Rear tire18.4-30Reference
2WD Standard tires (ag)Front: 10.00-16. Rear: 18.4-30Reference
4WD Standard tires (ag)Front: 12.4-24. Rear: 18.4-30Reference
2WD Optional tires (ag)Front: 11.00-16. Rear: 16.9-34Reference
Width209 cmReference
Height (ROPS)247 cmReference
Height (cab)257 cmReference
Rear tread149 to 200 cmReference
2WD ROPS3139 kgReference
4WD ROPS3369 kgReference
2WD Cab3549 kgReference
4WD Cab3779 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
